Bosch Split CS SM048 User Manual

SM Split CS Series Heat Pump
SM Split CS Series Heat Pump8733825873 (2020/05)
34 | Operating Temperatures and Pressures
Subject to change without prior notice
Table 19 SM048 Operating Temperatures and Pressures
Operating Temperatures and Pressures
Cooling Heating
Model
Entering
Water
Temp. F
Water
Flow
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Water
Temp.
Rise °F
Air
Temp.
Drop °F
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Water
Temp.
Drop
Air
Temp.
Rise °F
SM048
PART
LOAD
30°
6.0 64–78 248–303 5–6 15–18
12.0 67–82 254–311 3–4 16–19
40°
6.0 109–134 183–224 18–22 19–23 75–91 261–319 6–8 17–21
12.0 105–128 172–210 10–12 20–25 79–96 267–327 4–5 18–23
50°
6.0 118–144 214–261 18–22 19–23 78–90 273–334 8–10 20–24
12.0 113–138 201–245 10–12 20–24 82–95 280–342 5–7 21–26
60°
6.0 122–149 244–298 17–21 18–22 96–117 286–349 9–11 22–27
12.0 117–143 230–281 10–12 19–24 101–123 293–358 6–8 24–29
70°
6.0 126–154 275–336 17–21 18–22 107–131 299–365 11–13 25–30
12.0 121–148 258–316 10–12 19–23 113–138 306–374 7–9 26–32
80°
6.0 130–159 310–378 17–21 17–21 117–143 311–380 12–15 27–33
12.0 132–153 291–356 10–12 18–22 123–151 319–390 8–10 29–35
90°
6.0 134–164 349–426 17–20 17–20
12.0 129–158 328–401 9–12 18–22
100°
6.0 139–170 392–480 16–20 16–20
12.0 133–163 369–451 9–11 17–21
SM048
FULL
LOAD
30°
6.0 71–87 277–339 6–7 15–19
12.0 75–92 284–347 4–5 16–20
40°
6.0 118–144 194–237 21–25 19–23 84–102 291–356 7–9 18–22
12.0 113–138 182–223 12–14 20–24 88–108 299–365 5–6 19–23
50°
6.0 127–155 226–276 21–25 18–22 92–110 305–373 9–11 20–25
12.0 122–149 213–260 12–14 19–24 98–120 313–383 6–7 21–26
60°
6.0 131–160 259–316 21–25 18–22 108–132 320–391 10–13 23–28
12.0 126–154 243–297 12–14 19–23 113–138 328–400 7–9 24–29
70°
6.0 136–166 291–355 20–25 17–21 120–147 334–408 12–15 25–31
12.0 130–159 273–334 12–14 18–22 126–154 342–418 8–10 27–31
80°
6.0 140–171 328–401 20–24 17–20 131–161 348–425 14–17 27–34
12.0 135–165 308–377 11–14 18–22 138–169 356–436 9–11 29–36
90°
6.0 145–177 369–451 20–24 16–20
12.0 139–170 347–424 11–14 17–21
100°
6.0 149–183 415–508 19–24 16–19
12.0 143–175 391–477 11–14 17–21
This chart shows approximate temperatures and pressures for a unit in good repair. The values shown
are meant as a guide only and should not be used to estimate system charge. This chart assumes rated
airflow and 80º d.b./67º w.b. entering air temperature in cooling, 70º d.b. entering air temperature in
heating. Heating data at entering fluid temperatures below 50º assumes the use of antifreeze. As a result
of continuing research and development, specifications are subject to change without notice.
