Service Guide
■ Detailed Instruction (Step 5 For 3 Phase models)
- The pipe schematic below shows the location of the damper attachment.
- In the next page, damper structure added will be explained in four parts, such as whole part,
Accumulator part, Comp_Discharge part, Comp_Suction part.
(Only show pipe structure)
Pipe Schematic
(15 of 25)
