Service Guide
■ Detailed Instruction (Step 5 For 1 Phase models)
- The only difference compared to instruction for 3 phase model is that you need to Add additionally
Damper (Ø19.05) shown below.
- The remaining of Damper structure for service is same with 3 phase models.
Damper Structure for Service
Add
Damper (Ø 19.05)
additionally
Remove
Damper
Origin Damper structure of 1 Phase model
(21 of 25)
