1. Overview
The TouchOne is a High Denion, 7” Touchscreen Keypad for Bosch Soluon 2000 and
3000 control panels that provides a rich user interface and extended funconality to the
end user.
Generaon 2 builds on the powerful foundaon of the TouchOne with an all new Processor,
SmartColor display system, new touch panel and improved mounng design.
2. Wiring
Using the included Wire Harness, wire the TouchOne into the
control panel as per the wiring diagram. It is recommended to
solder the wires to the cable from the control panel.
Noce on Power Consumpon
The TouchOne consumes considerably more power than
a tradional codepad due to its HD screen and internet
connecvity. Only one TouchOne device can be powered
by the control panel to ensure reliable performance. Up to 4 TouchOne devices can
be connected to one system, however 3 of them must be powered by a seperate and
appropriately rated power supply.
Using a 0.5mm cable from the control panel with a run less than 15 meters is recommended
for best performance.
