Required material for installing the parking lot sensor
Figure 2 Material for attachment
3. Disposable gloves (protection against contact with adhesive)
4. Two-component adhesive (here: DELO®-PUR 9692, 50 ml)
5. Adhesive press (these differ, depending on the cartridge size)
6. Mixing tip
7. Tape rule
8. Sensor base
9. Sensor core (sensor)
10. T20 screw
11. Sensor cap (sensor sealing cap)
Preparation of the parking space
The parking space must be free of dirt, dust, oil, water and other contaminants. For this purpose, at least one swept
area should be prepared. However, it is recommended to clean the surface to remove contamination using a high-
pressure cleaner and a burner.
The installation must take place in the center of the parking space (intersection of the two diagonals, see Fig. 3) in
order to ensure optimum sensor accuracy.
Figure 3 Determination of the center of the parking space
