1 Menu bar Allows you to select a menu command.
2 Toolbar Displays the available buttons. Point to an icon to
display a tooltip.
3 Playback controls Allows you to control instant playback or a camera
sequence or alarm sequence.
4 Performance meter Displays the CPU usage and the memory usage.
5 Time zone selector Select an entry for the time zone to be displayed in
most time related fields.
Only available if at least one Management Server in
the Logical Tree is located in another time zone as
your Operator Client.
6 Slider for Image pane pattern Allows you to select the required number of Image
panes.
7 Image window Displays the Image panes. Allows you to arrange the
Image panes.
Bosch Video Management System User interface | en 65
Bosch Sicherheitssysteme GmbH Operator's Manual 2013.07 | V1 | Operator Client
