Removing the transport securing devices
Figure 1 Figure 2.1
Figure 2.3
13
1
1
2
2
A
1 Remove the machine from the transport
base.
Remove wedge
훽
(Figure 1 ).
2 Remove the 4 screws
훾
with a screwdriver
(Figure 2.1 ).
3 Remove transport securing device
훿
Remove both screws

(Figure 2.2 ) using
a number 10 or 13 spanner (depending upon
the model).
Check to see that both plastic inserts on
the connecting carrier have also been
removed.
Reinstall screws
훾
in their original positions.
4

Both holes must be covered with the
caps provided

(found in the accessories
package)
( Figure 2.3 )!

Before the machine is used for the first time, all transport securing devices from
the back of the appliance must be removed and stored for any later transport
(i.e., relocation).
Figure 2.2
