8 | General information US
Copyright6 720 646 951 (2011/09)
2.7 Wiring diagram
Fig. 3 Internal wiring schematic for single phase WH27 unit.
DANGER: Risk of electric shock!
B Always switch off the electricity supply to
the unit before any intervention in the
heater.
