Bose 1801 Service Manual

15
PART LIST
Main Part List (per figures 1-7)
Item
Number
Description Part
Number
Note
8 Rubber Foot 121929
F1 Fuse (110v)15A, 1 1/4 x 1/4Slo-Blo 103608
F1 Fuse (220v) 8A, 5 x 20mm 108190-800
F1 Fuse (220v) 7A, 1 1/4 x 1/4Slo-Blo 103609
¥ Fuse Cap for 1 1/4 x 1/4 109484 9
¥ Fuse Cap for 5 x 20mm 109493 9
9 Front Panel Assy 103380 1, 7
10 Front Panel Assy 121910 1, 8
11¥ Rear Panel Assy 103282 1, 7, 9
12 Rear Panel Assy 103266 1, 8
13 Amp PCB Complete 102735-1 1
14 L.E.D Board Complete 102751 1
Carton and Fillers 103268
15 Heat Sink Side 102536 1
16 Heat Sink Corner 102474 1
17 Top Cover 102544 1, 7
18 Top Cover 121930 1, 8
19 Screw Heat Sink 103041
¥ Accessory Kit 102745 1, 7, 9
¥ Accessory Kit 103361 1, 8, 9
20 Black Binding Post 109068-0
21 Red Binding Post 109068-2
22 Blue Binding Post 109068-6
23 Black Binding Post Base 109069-0
24 Fuse Holder 109485
25 Strain Relief 102708

Bose 1801 Specifications

General

Power Output	250 watts per channel into 8Ω (stereo)
Frequency Response	20Hz to 20kHz
Damping Factor	200
Input Sensitivity	1.5V
Speaker Load Impedance	4Ω to 8Ω
Total Harmonic Distortion	0.5%
