ELECTRICAL PART LIST
Diodes
Reference
Designator
Description Bose
®
Part
Number
Vendor Part
Number
Note
D600 1N4002 262192 3100.0005
D601 1N4002 262192 3100.0005
D610 SWITCHING, MUR120, AXL - L.3100.0001 4
D611 SWITCHING, MUR120, AXL - L.3100.0001 4
D614 SWITCHING, MUR120, AXL - L.3100.0001 4
D615 SWITCHING, MUR120, AXL - L.3100.0001 4
D620 SWITCHING, MUR120, AXL - L.3100.0001 4
D621 SWITCHING, MUR120, AXL - L.3100.0001 4
D624 SWITCHING, MUR120, AXL - L.3100.0001 4
D625 SWITCHING, MUR120, AXL - L.3100.0001 4
Transistors
Reference
Designator
Description Bose Part
Number
Vendor Part
Number
Note
Q601 PNP, 2N4403TO-92 262134 3200.0002
Q610 N-CH FET, STW34NB20, TO-247 - L.3210.0017 4
Q611 N-CH FET, STW34NB20, TO-247 - L.3210.0017 4
Q620 N-CH FET, STW34NB20, TO-247 - L.3210.0017 4
Q621 N-CH FET, STW34NB20, TO-247 - L.3210.0017 4
Integrated Circuits
Reference
Designator
Description Bose Part
Number
Vendor Part
Number
Note
U602 VOLT REG, L7805CP, ISOWATT 220 262137 3430.0007
U603 OP AMP, DUAL, X072, DIP 262124 3410.0004
U604 OP AMP, DUAL, X072, DIP 262124 3410.0004
Amplifier PCB Assembly (board part number 8005.0587)
Amplifier Driver PCB Assembly (used with amplifier board part number 8005.0587)
Reference
Designator
Description Bose Part
Number
Vendor Part
Number
Note
U901/U902 AMPLIFIER DRIVER SET, 300W,
TRIPATH TK2350
317790-001S - 3
