15
ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description Part
Number
Note
R144, 244 56kΩ, 1/4 Watt, 2% 117704-
1215632
R148, 248 4.12kΩ, 1/4 Watt, 1% 119976-
2214121
R149, 249 23.7kΩ, 1/4 Watt, 1% 119976-
2212372
R150, 250 30.9kΩ, 1/4 Watt, 1% 119976-
2213092
R160, 260 22kΩ, 1/4 Watt, 5% 117704-
1212235
SMD Resistors
Reference
Designator
Description Part
Number
Note
R1, 2 2.7kΩ, CHIP, 5% 124895-2725
R3, 4 3.3kΩ, CHIP, 5% 124895-3325
R5, 6, 7, 11, 15, 118, 218 160kΩ, CHIP, 5% 124895-1645
R8, 9, 12, 13, 16, 101, 104 330kΩ, CHIP, 5% 124895-3345
R102, 103, 105, 111, 122, 124, 202,
203, 205, 211, 222, 224
2.00kΩ, CHIP, 1% 124894-2001
R106, 206 1,91kΩ, CHIP, 1% 124894-1911
R107, 207 48.7kΩ, CHIP, 1% 124894-4872
R108, 208 20kΩ, CHIP, 5% 124895-2035
R109, 126, 130, 131, 209, 226, 230,
231
23.7kΩ, CHIP, 1% 124894-2372
R110, 210 2.74kΩ, CHIP, 1% 124894-2741
R112, 114, 212, 214 13.3kΩ, CHIP, 1% 124894-1332
R113, 213 1kΩ, CHIP, 5% 124895-1025
R115, 215 10kΩ, CHIP, 5% 124895-1035
R116, 125, 139, 152, 216, 225, 239,
252
8.25kΩ, CHIP, 1% 124894-8251
R117, 128, 129, 133, 134, 217, 228,
229, 233, 234
6.81kΩ, CHIP, 1% 124894-6811
R119, 120, 219, 220 18kΩ, CHIP, 5% 124895-1835
R121, 136, 160, 221, 236, 260 22kΩ, CHIP, 5% 124895-2235
R123, 223 470Ω, CHIP, 5% 124895-4715
R127, 227 130kΩ, CHIP, 5% 124895-1345
R132, 141, 145, 147, 151, 153-158,
232, 241, 245, 247, 251, 253-258
6.04kΩ, CHIP, 1% 124894-6041
R137, 237 47.5kΩ, CHIP, 1% 124894-4752
R142, 242 3.01kΩ, CHIP, 1% 124894-3011
R143, 149, 150, 234, 249, 250 33kΩ, CHIP, 5% 124895-3335
R144, 244 56.2kΩ, CHIP, 1% 124894-5622
R146, 246 4.75kΩ, CHIP, 1% 124894-4751
R164, 264 26.7kΩ, CHIP, 1% 124894-2672
To Next Page
