Bose 802C

16
ELECTRICAL PART LIST
Capacitors
Reference
Designator
Description Part
Number
Note
C1 .0047uF, 220V
.0047uF, 1.4KV, 100/120V
120993
103447
3
C2, 3 .015uF, FILM 118091-153
C4 .01uF, CERAMIC DISC 119696-103
C5, 6 470uF, ELECTROLYTIC 110704
C7-10 1uF, ELECTROLYTIC 119942-1R0
C11-19, 22 .1uF, CERAMIC DISC 117502
C101, 117, 125, 201, 217, 225 22uF, ELECTROLYTIC 119944-220
C102, 202 2.2uF, ELECTROLYTIC 119943-2R2
C103-105, 203-205 .0068uF, FILM 118091-682
C106, 206 .33uF, FILM 123785-334
C107, 108, 121, 122, 207, 208, 221,
222
.1uF, FILM 118091-104
C109, 209 .0012uF, FILM 118091-122
C110, 126, 127, 210, 226, 227 470pF, CERAMIC DISC 119617-471
C111, 211 270pF, CERAMIC DISC 119617-271
C112, 113, 124, 212, 213, 224 .033uF, FILM 118091-333
C114, 214 .068uF, FILM 118091-683
C115, 116, 123, 215, 216, 223 .047uF, FILM 118091-473
C118, 119, 218, 219 .082uF, FILM 118091-823
C120, 220 .022uF, FILM 118091-223
SMD Capacitors
Reference
Designator
Description Part
Number
Note
C4 .01uF, CERAMIC, CHIP 124959-103
C11-22 .1uF, CERAMIC, CHIP 124959-104
C110, 126, 127, 210, 226, 227 470pF, CERAMIC, CHIP,
10%
124956-4712
C111, 211 270pF, CERAMIC, CHIP,
10%
124956-2742
