Bose ControlSpace EX-1280C Service Manual

19
Reference
Designator
Description Vendor Vendor Part Number Note
R418 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R419 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R420 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R446 100, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1000X
R447 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R448 0.0, 1/10W, JUMPER, 0402, SM PANASONIC ERJ-2GE0R00X
R449 0.0, 1/10W, JUMPER, 0402, SM PANASONIC ERJ-2GE0R00X
R450 100, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1000X
R451 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R452 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R453 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R454 0.0, 1/10W, JUMPER, 0402, SM PANASONIC ERJ-2GE0R00X
R455 0.0, 1/10W, JUMPER, 0402, SM PANASONIC ERJ-2GE0R00X
R456 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R457 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R458 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R459 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R460 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R461 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R462 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R463 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R464 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R465 100, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1000X
R466 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R467 100K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1003X
R468 43.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF4302X
R469 2.55K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF2551X
R470 11.5K, 1/10W, 1%, 0402 PANASONIC ERJ-2RKF1152X
R471 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R472 1.00K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1001X
R473 1.78K, 1/10W, 0402, 1% PANASONIC ERJ-2RKF1781X
R474 20.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF2002X
R475 0.0, 1/10W, JUMPER, 0402, SM PANASONIC ERJ-2GE0R00X
R476 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R477 20.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF2002X
R478 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R480 20.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF2002X
R481 680K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF6803X
R482 10.0K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1002X
R484 130K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1303X
R485 1.00K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF1001X
R486 0.0, 1/10W, JUMPER, 0402, SM PANASONIC ERJ-2GE0R00X
R487 0.0, 1/10W, JUMPER, 0402, SM PANASONIC ERJ-2GE0R00X
MAIN DSP PCB PART LIST
Resistors (continued)
