Bose ControlSpace EX-1280C Service Manual

100
OLED PCB PART LIST
Resistors
Reference
Designator
Description Vendor Vendor Part Number Note
R1 39.2K, 1/10W, 1%, 0402, SM PANASONIC ERJ-2RKF3922X
R2 4.32K, 1/10W, 1%, 0603, SM PANASONIC ERJ-3EKF4321V
R3 10.0K, 1/10W, 1%, 0402 PANASONIC ERJ-2RKF1002X
R4 10.0K, 1/10W, 1%, 0402 PANASONIC ERJ-2RKF1002X
R5 10.0K, 1/10W, 1%, 0402 PANASONIC ERJ-2RKF1002X
R6 4.7K, 1/10W, 5%, 0603 PANASONIC ERJ-3GEYJ472V
R8 4.7K, 1/10W, 5%, 0603 PANASONIC ERJ-3GEYJ472V
R9 4.7K, 1/10W, 5%, 0603 PANASONIC ERJ-3GEYJ472V
R10 10.0K, 1/10W, 1%, 0402 PANASONIC ERJ-2RKF1002X
R12 681 OHM, 1/10W, 1%, 0603 PANASONIC ERJ-3EKF6810V
R14 4.7K, 1/10W, 5%, 0603 PANASONIC ERJ-3GEYJ472V
R15 4.7K, 1/10W, 5%, 0603 PANASONIC ERJ-3GEYJ472V
R16 10.0K, 1/10W, 1%, 0402 PANASONIC ERJ-2RKF1002X
R17 10.0K, 1/10W, 1%, 0402 PANASONIC ERJ-2RKF1002X
R18 10.0K, 1/10W, 1%, 0402 PANASONIC ERJ-2RKF1002X
Capacitors
Reference
Designator
Description Vendor Vendor Part Number Note
C1 CER, 4.7UF, 25V, 20%, X5R, 0805 MURATA GRM21BR61E475MA12L
C2
CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
C3 ELYT, ALUM, 47UF, 25V, 20%, SM PANASONIC EEE-1EA470WP
C4 CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
C5 ELYT, ALUM, 47UF, 25V, 20%, SM PANASONIC EEE-1EA470WP
C6 CER, 4.7UF, 25V, 20%, X5R, 0805 MURATA GRM21BR61E475MA12L
C7 CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
C8 CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
C9 ELYT, ALUM, 47UF, 25V, 20%, SM PANASONIC EEE-1EA470WP
C10 CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
C11 CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
C12 CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
C13 CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
C14 ELYT, ALUM, 47UF, 25V, 20%, SM PANASONIC EEE-1EA470WP
C15 CER, 0.1UF, 25V, 10%, X7R, 0402 TDK CGA2B3X7R1E104K
Diodes
Reference
Designator
Description Vendor Vendor Part Number Note
D1 215MA, 70V, DUAL, SERIES, SOT-23-3 ON SEMI BAV99LT1G
D2 215MA, 70V, DUAL, SERIES, SOT-23-3 ON SEMI BAV99LT1G
D3 215MA, 70V, DUAL, SERIES, SOT-23-3 ON SEMI BAV99LT1G
D4 215MA, 70V, DUAL, SERIES, SOT-23-3 ON SEMI BAV99LT1G
D5 215MA, 70V, DUAL, SERIES, SOT-23-3 ON SEMI BAV99LT1G
