Bose ControlSpace EX-1280C Service Manual

8
PACKAGING PART LIST
ControlSpace
®
EX 1280C (see Figure 1)
Figure 1. Packaging Exploded View
1
2
3
4
5
6
7
Item Num-
ber
Description Part Number Qty. Note
1 CARTON, DSP, SVC 785543-001S 1
2 CONNECTOR KIT, DSP 787147-001S 1
3 PEARL FORM, ENDCAP, SVC 785550-001S 2
4 POLY BAG, L420XW550MM 785546-0010 1
5 POLY BAG, L320xW217x0.5mm (INSTALL GUIDE) - 1
6 GUIDE, INSTALL, DSP 788755-0010 1
7 WAFER SEAL, 80MM - 1
-
AC LINE CORD, IEC, C13, US/CAN
350745-0010 1 3
AC LINE CORD, IEC, C13, EURO 350747-0010 1
AC LINE CORD, IEC, C13, JAPAN 350749-0020 1
AC LINE CORD, IEC, C13, UK 350748-0010 1
AC LINE CORD, IEC, C13, AUS 350746-0010 1
