Bose ControlSpace EX-1280C Service Manual

9
MAIN PART LIST
ControlSpace
®
EX 1280C (see Figure 2)
Item
Number
Description Part Number Qty. Note
1 HARNESS, PS-MAIN, 22AWG, 10 COND 370437-0010 1 3
2 CABLE, GROUND INLET, GRN/YEL (AC GROUND) 530498-001S 1 3
3 COVER, DSP, BLK, SVC (TOP COVER) 777061-011S 1
4 SCREW, MSB, M3x6MM, BLACK - 11
5 SCREW, SI, MSF, M3x5.5MM 370493-0110 4
6 SCREW, MSB, M3x6MM, W/WASHER - 22
7 PCB ASSY, OUTPUT, 8 CHANNEL 772393-001S 1 1
8 SCREW, M4x9MM, CARBON STEEL - 4
9 BRACKET, RACK MOUNT, DSP, BLK, SVC 772790-011S 2
10 PCB ASSY, DISPLAY 773012-001S 1 1
11 OLED, DISPLAY ASSY (W/O DISPLAY PCB & KNOB) 785548-001S 1
12 COVER, DISPLAY, DSP, SVC (DISPLAY LENS) 772794-011S 1
13 SCREW, HEX SET, M3 (USED FOR KNOB) - 1
14 KNOB, DSP, BLK, SVC 772791-011S 1
15 PANEL, FRONT, DSP, BLK, SVC 771614-011S 1
16 FAN, 5VDC, 40mm 772567-001S 2 3
17 NUT, LOCKING, HEX, M4, W/NYLON - 2
18 CABLE FFC, 24 POS, 80MM (MAIN PCB TO DISPLAY) 785538-002S 1
19 CABLE FFC, 40 POS, 32MM (MAIN TO INPUT PCB) 788169-001S 1
20 CABLE FFC, 40 POS, 58MM (MAIN TO OUTPUT PCB) 788169-002S 1
21 CABLE FFC, 24 POS, 30MM (MAIN TO PSTN PCB) 785538-001S 1
22 STANDOFF, 14MM 370491-0010 9
23 PCB ASSY, MAIN DSP 772390-001S 1 1
24 INSULATOR SHEET, SVC 777066-001S 1 3
25 PCB ASSY, POWER SUPPLY, DSP 772568-001S 1 1
26 PCB ASSY, ACOUSTIC ECHO CANCEL (AEC) 772789-001S 1 1
27 SCREW, SI, MSB, M3x8MM, CARBON STEEL, BLACK - 2
28 SCREW, MSB, 3x5MM, W/WASHER - 1
29 STANDOFF, 5.5MM - 1
30 PCB ASSY, BROOKLYN II PCB (DANTE CARD) 788741-001S 1
31 PCB ASSY, INPUT, 12 CHANNEL 772391-001S 1 1
32 PCB ASSY, PUBLIC SWITCH TELEPHONE NETWORK
(PSTN)
772582-001S 1 1
