Bose ControlSpace EX-1280C Service Manual

62
OUTPUT PCB PART LIST
Resistors
Reference
Designator
Description Vendor Vendor Part Number Note
R100 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R101 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R102 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R103 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R104 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R105 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R106 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R107 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R108 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R109 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R110 47 OHM, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD47R0F
R111 47 OHM, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD47R0F
R114 1M, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD1004F
R115 1M, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD1004F
R116 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R117 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R118 10 OHM, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD10R0F
R120 33 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD33R0F
R121 33 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD33R0F
R122 120K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD1203F
R123 120K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD1203F
R150 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R151 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R152 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R153 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R154 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R155 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R156 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R157 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R158 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R159 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R160 47 OHM, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD47R0F
R161 47 OHM, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD47R0F
R164 1M, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD1004F
R165 1M, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD1004F
R166 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R167 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R168 10 OHM, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD10R0F
R169 10 OHM, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD10R0F
R170 33 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD33R0F
R171 33 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD33R0F
R172 120K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD1203F
R173 120K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD1203F
