Bose ControlSpace EX-1280C Service Manual

61
U1850 NJM4580E-TE1-#ZZZB, EMP8 NJRC NJM4580E-TE1
U1851 NJM4580E-TE1-#ZZZB, EMP8 NJRC NJM4580E-TE1
U1900 ADC, AK5388AEQ AKM Semi AK5388AEQ
U1950 ADC, AK5388AEQ AKM Semi AK5388AEQ
U2000 ADC, AK5388AEQ AKM Semi AK5388AEQ
U2050 I2C, BUS, PCA9505DGG, 118 TSSOP NXP Semi PCA9505DGG,118
U2051 SINGLE2-INPUT, SN74LVC1G08DCKR, SC70 TI SN74LVC1G08DCKRE4
U2100 I2C, BUS, PCA9505DGG, 118 TSSOP NXP Semi PCA9505DGG,118
U2101 SINGLE2-INPUT, SN74LVC1G08DCKR, SC70 TI SN74LVC1G08DCKRE4
U2150 I2C, BUS, PCA9505DGG, 118 TSSOP NXP Semi PCA9505DGG,118
U2151 SINGLE2-INPUT, SN74LVC1G08DCKR, SC70 TI SN74LVC1G08DCKRE4
U2200 BA17805FP-E2 Rohm BA17805FP-E2
INPUT PCB PART LIST
Integrated Circuits (continued)
Miscellaneous
Reference
Designator
Description Vendor Vendor Part Number Note
J2203 FPC, CONN, 0.5MM PITCH TE Conn. 4-1734839-0
J2204 CONN, 6P, 1803316 Phoenix 1803316
J2205 CONN, 6P, 1803316 Phoenix 1803316
J2206 CONN, 6P, 1803316 Phoenix 1803316
J2207 CONN, 6P, 1803316 Phoenix 1803316
J2208 CONN, 6P, 1803316 Phoenix 1803316
J2209 CONN, 6P, 1803316 Phoenix 1803316
- MOUNTING BRACKET, BSE30A1, M3 THREAD Keystone 7790 Qty.2
