Bose ControlSpace EX-1280C Service Manual

99
ACOUSTIC ECHO PCB PART LIST
Transistors
Reference
Designator
Description Vendor Vendor Part Number Note
Q1 TR, NPN, 65V, 100MA, SOT-23 NXP BC846B,215
Q2 TR, NPN, 65V, 100MA, SOT-23 NXP BC846B,215
Q3 TR, NPN, 65V, 100MA, SOT-23 NXP BC846B,215
Q10 MOSFET, P-CH, 30V, 4A, SOT-23 ALPHA AND
OMEGA SEMI
AO3401A
Integrated Circuits
Reference
Designator
Description Vendor Vendor Part Number Note
U1 PMMMPF0100F0AEP, QFN FREESCALE
SEMI
MMPF0100F0AEP
U2 DC-DC CONVERTER, LM3671MFX-1.2/
NOPB, SOT23
TI LM3671MFX-1.2/NOPB
U3 ESD PROTECT, IP4220CZ6, 125, CS-74 NXP IP4220CZ6,125
U4 ESD PROTECT, IP4220CZ6, 125, CS-74 NXP IP4220CZ6,125
U5 MPU MCIMX6Q5EYM10AD, FCPBGA FREESCALE
SEMI
MCIMX6Q5EYM10AD
U6 SDRAM, MT41K128M16JT-125:K, TR, TFBGA Micron Semi MT41K128M16JT-125:K TR
U7 SDRAM, MT41K128M16JT-125:K, TR, TFBGA Micron Semi MT41K128M16JT-125:K TR
U8 SDRAM, MT41K128M16JT-125:K, TR, TFBGA Micron Semi MT41K128M16JT-125:K TR
U9 SDRAM, MT41K128M16JT-125:K, TR, TFBGA Micron Semi MT41K128M16JT-125:K TR
U10 ETHERNET TRANSCEIVERS, KSZ9031RNX-
CA, TR, QFNROHS
MICREL
SEMI
KSZ9031RNXCA TR
U11 BUFFER, SN74LVC541APWT, TSSOP TI SN74LVC541APWT
U12 LDO, MIC94310-4YMT, TR, DFN MICREL
SEMI
MIC94310-4YMT TR
U13 VOLT SPRVSR, TPS3808G18DBVR TI TPS3808G18DBVR
U27 ESD PROTECT, IP4220CZ6, 125, CS-74 NXP IP4220CZ6,125
U28 NAND, FLASH, MTFC8GACAAAM-4M-IT,
VFBGA
Micron Semi MTFC8GACAAAM-4M-IT
U38 ESD PROTECT, IP4220CZ6, 125, CS-74 NXP IP4220CZ6,125
Miscellaneous
Reference
Designator
Description Vendor Vendor Part Number Note
P1 HEADER, 41P, 91911-31341LF FCI 91911-31341LF
XTAL1 CRYSTAL, SMT, 24.0000MHZ, 9PF, 10PPM,
SMD
Epson (HK)
LTD.
TSX-3225 24.0000MF 15X-
AC3
XTAL2 CRYSTAL, SMT, 25.0000MHZ, 18PF, 30PPM,
SMD
TXC CORPO-
RATION
7B-25.000MAAJ-T
