Bose ControlSpace EX-1280C Service Manual

98
ACOUSTIC ECHO PCB PART LIST
Capacitors (continued)
Reference
Designator
Description Vendor Vendor Part Number Note
C395 X5R, 0.22UF, 10V, 10%, 0201, 55C, T&R TDK C0603X5R1A224KT00NN
C396 X5R, 0.22UF, 10V, 10%, 0201, 55C, T&R TDK C0603X5R1A224KT00NN
C397 22UF, X5R, 6.3V, 20%, 0603, 85C, T&R Murata GRM188R60J226MEA0D
C398 X5R, 0.22UF, 10V, 10%, 0201, 55C, T&R TDK C0603X5R1A224KT00NN
C399 X5R, 0.22UF, 10V, 10%, 0201, 55C, T&R TDK C0603X5R1A224KT00NN
C400 X5R, 0.22UF, 10V, 10%, 0201, 55C, T&R TDK C0603X5R1A224KT00NN
C402 X7R, 0.1UF, 25V, 10%, 0402, 125C, T&R TDK C1005X7R1E104KT000F
C413 X5R, 1UF, 25V, 10%, 55C, 0603, T&R Murata GRM188R61E105KA12D
C414 X5R, 1UF, 25V, 10%, 55C, 0603, T&R Murata GRM188R61E105KA12D
C415 X5R, 1UF, 25V, 10%, 55C, 0603, T&R Murata GRM188R61E105KA12D
C455 X7R, 0.22UF, 16V, 10%, 55C, 0402, T&R Murata GRM155R71C224KA12D
Ferrite Beads
Reference
Designator
Description Vendor Vendor Part Number Note
FB1 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB2 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB3 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB4 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB5 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB6 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB7 SMT, FERR BEAD, 120 OHM, 25%, 3500MA,
0805
LAIRD TECH HI0805O121R-10
FB8 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB10 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB59 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
FB60 SMT, FERR BEAD, 1K, 25%, 100MA, 0603 Murata BLM18AG102SN1D
Inductors
Reference
Designator
Description Vendor Vendor Part Number Note
CM1 INDUCTOR, 90 OHM, 25%, 330MA, 0805 Murata DLW21SN900SQ2L
L1 INDUCTOR, 1UH, 20%, 15A, 7.2X6.65MM ABRACON ASPI-0630LR-1R0M-T15
L2 INDUCTOR, 1UH, 20%, 15A, 7.2X6.65MM ABRACON ASPI-0630LR-1R0M-T15
L3 INDUCTOR, 1UH, 20%, 15A, 7.2X6.65MM ABRACON ASPI-0630LR-1R0M-T15
L4 INDUCTOR, 3.3UH, 20%, 1210MA, 3X3MM TAIYOYUD-
EN
NR3015T3R3M
L5 INDUCTOR, 3.3UH, 20%, 1210MA, 3X3MM TAIYOYUD-
EN
NR3015T3R3M
Diodes
Reference
Designator
Description Vendor Vendor Part Number Note
D1 DIODE, RECT, MBR230LSFT1G, SOD-123 ON Semi MBR230LSFT1G
D2 SMT, DIODE, RECTIFIER, S2A-13-F, SMB DIODES INC S2A-13-F
D49 SMT, DIODE, SW, BAV99, SOT-23 Fairchild BAV99
D50 SMT, DIODE, SW, BAV99, SOT-23 Fairchild BAV99
