48
Reference
Designator
Description Vendor Vendor Part Number Note
R2103 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2104 20K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD2002F
R2105 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2106 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2150 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2151 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2152 20K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD2002F
R2153 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2154 20K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD2002F
R2155 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2156 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2200 4.7 OHM, 1/2W, 1210, 1% Panasonic ERJ-14BQF4R7U
R2201 4.7 OHM, 1/2W, 1210, 1% Panasonic ERJ-14BQF4R7U
R2202 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2203 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2204 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2207 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2209 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2211 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2212 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2213 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2214 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2215 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2216 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2217 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R2218 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2219 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2220 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2221 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2222 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2223 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2224 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R2225 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
INPUT PCB PART LIST
Resistors (continued)
Capacitors
Reference
Designator
Description Vendor Vendor Part Number Note
C1000 Y5V ,0.1UF, 50V, 20%, 0603 Murata GRM188F11H104ZA01D
C1001 SMD, E 4.7UF, 63V, 20%, 40C United EMVA630ADA4R7ME55G
C1002 Y5V ,0.1UF, 50V, 20%, 0603 Murata GRM188F11H104ZA01D
C1003 SMD, E 4.7UF, 63V, 20%, 40C United EMVA630ADA4R7ME55G
C1004 SMD, E 4.7UF, 63V, 20%, 40C United EMVA630ADA4R7ME55G
C1005 100PF, 50V, 5%, 0603 Murata GRM1882C1H101JA01D
