Bose ControlSpace EX-1280C Service Manual

87
PSTN PCB PART LIST
Resistors (continued)
Reference
Designator
Description Vendor Vendor Part Number Note
R50 THICK FC, 1210, 73.2 Ohm, 1% Panasonic ERJ-14NF73R2U
R51 THICK FC, 100K, 1/10W, 0603, 1% Panasonic ERJ-3EKF1003V
R52 THICK FC, 0603, 150 Ohm, 1% Panasonic ERJ-3EKF1500V
R53 THICK FC, 1210, 2.49K, 1% Panasonic ERJ-14NF2491U
R54 THICK FC, 0603, 56 Ohm, 1% Samsung RC1608F560CS
R55 THICK FC, 100K, 1/10W, 0603, 1% Panasonic ERJ-3EKF1003V
R56 THICK FC, 0603, 56 Ohm, 1% Samsung RC1608F560CS
R57 THICK FC, 1M, 1/10W, 0603, 1% Panasonic ERJ-3EKF1004V
R58 THICK FC, 1/8W, 5.1M, 1% Vishay/Dale CRCW08055M10FKEA
R59 THICK FC, 0805, 15M, 5% Stackpole RMCF0805JT15M0
R60 THICK FC, 1/8W, 5.1M, 1% Vishay/Dale CRCW08055M10FKEA
R61 THICK FC, 0805, 15M, 5% Stackpole RMCF0805JT15M0
R62 THICK FC, 1K, 1/10W, 0603, 1% Panasonic ERJ-3EKF1001V
R63 THICK FC, 10K, 1/10W, 0603, 1% Panasonic ERJ-3EKF1002V
Capacitors
Reference
Designator
Description Vendor Vendor Part Number Note
C1 X5R, 1UF, 10V, 10% 85C, 0603 TDK C1608X5R1A105K080AC
C3 X5R, 1UF, 10V, 10% 85C, 0603 TDK C1608X5R1A105K080AC
C4 0603, 18Pf, 50V, 5%, NPO TDK C1608C0G1H180J
C5 0603, 18Pf, 50V, 5%, NPO TDK C1608C0G1H180J
C6 X5R, 1UF, 10V, 10% 85C, 0603 TDK C1608X5R1A105K080AC
C7 X7R, 10NF, 50V, 10%, 125C, 0603 AVX 06035C103KAT2A
C8 X7R, 10NF, 50V, 10%, 125C, 0603 AVX 06035C103KAT2A
C9 X7R, 1NF, 50V, 10%, 125C, 0603 AVX 06035C102KAT2A
C10 0603, 2.7Nf, 50V, 10%, X7R Samsung CL10B272KB8NNNC
C11 X7R, 1UF, 50V, 10%, 0805 TDK C2012X7R1H105K085AC
C12 X7R, 10NF, 50V, 10%, 125C, 0603 AVX 06035C103KAT2A
C13 Y3, 33PF, 5KV, 10%, 2211 Novacap ES2211N330K502NT
C14 Y3, 33PF, 5KV, 10%, 2211 Novacap ES2211N330K502NT
C15 X7R, 0.1UF, 16V, 10%, 125C, 0603 AVX 0603YC104KAT2A
C16 X7R, 0.1UF, 16V, 10%, 125C, 0603 AVX 0603YC104KAT2A
C17 X7R, 0.1UF, 16V, 10%, 125C, 0603 AVX 0603YC104KAT2A
C18 0805, 3.9NF, 250V, 10%, X7R AVX 0805PC392KAT1A
C19 0805, 100PF, 600VAC, 10%, X7R AVX 0805CA101KAT1A
C20 2211, 680PF, 5KV, 10%, Y3 Novacap ES2211N681K502NTM 3
C21 0805, 100PF, 600VAC, 10%, X7R AVX 0805CA101KAT1A
C22 2211, 680PF, 5KV, 10%, Y3 Novacap ES2211N681K502NTM 3
C23 X7R, 1NF, 50V, 10%, 125C, 0603 AVX 06035C102KAT2A
