Bose F1 812 Service Manual

12
Product Description
Connection Modes (continued)
Mobile device to F1 model 812 loudspeaker and F1 subwoofer
F1 Model 812
F1 Subwoofer
Set F1
Model 812
EQ to
WITH SUB.
Mobile device headphone
output to F1 Model 812
INPUT 2 RCA connectors.
DJ Console to two F1 Subwoofers and two F1 Model 812 loudspeakers
F1 Model 812-2F1 Subwoofer-2
F1 Subwoofer-1 F1 Model 812-1

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
