PART LIST NOTES
1. The individual parts located on the PCBs are listed in the Electrical Part List.
2. This part is referenced for informational purposes only. It is not stocked as a repair part.
Refer to the next higher assembly for a replacement part.
3. This part is critical for safety purposes. Failure to use a substitute replacement with
the same safety characteristics as the recommended replacement part might create shock,
fire and/or other hazards.
ELECTROSTATIC DISCHARGE SENSITIVE (ESDS)
DEVICE HANDLING
This unit contains ESDS devices. We recommend the following precautions when repairing,
replacing or transporting ESDS devices:
• Perform work at an electrically grounded work station.
• Wear wrist straps that connect to the station or heel straps that connect to conductive
floor mats.
• Avoid touching the leads or contacts of ESDS devices or PC boards even if properly
grounded. Handle boards by the edges only.
• Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert
unprotected devices into materials such as plastic, polystyrene foam, clear plastic bags,
bubble wrap or plastic trays.
Manufactured Versions
Material Master
Number
Description
F1 Model 812 Flexible Array Loudspeake
731419-0110 F1 MODEL 812 FLEX ARRAY LDSPKR NO POWER CORD
731419-1110 F1 MODEL 812 FLEX ARRAY LDSPKR 120V US
731419-2110 F1 MODEL 812 FLEX ARRAY LDSPKR 230V EU
731419-3110 F1 MODEL 812 FLEX ARRAY LDSPKR 100V JP
731419-4110 F1 MODEL 812 FLEX ARRAY LDSPKR 230V UK
731419-5110 F1 MODEL 812 FLEX ARRAY LDSPKR 220V AU
F1 Subwoofer
731444-0110 F1 SUBWOOFER POWERED NO POWER CORD
731444-1110 F1 SUBWOOFER POWERED 120V US
731444-2110 F1 SUBWOOFER POWERED 230V EU
731444-3110 F1 SUBWOOFER POWERED 100V JP
731444-4110 F1 SUBWOOFER POWERED 230V UK
731444-5110 F1 SUBWOOFER POWERED 230V AU
