19
MAIN PART LIST
F1 Model 812 Flexible Array Loudspeaker (refer to Figure 3)
Item
Number
Description Part
Number
Qty. Note
1 GRILLE, SIDE, MH, SERV 625268-011S 2
2 KIT, LOGO, ASSY, MH, BLK, SVCE 720197-011S 1
3 GRILLE, ARRAY, CENTER , SERV 625267-011S 1
4 GRILLE, ARRAY, SERV 625266-011S 6
5 SCREW, M4X1.5X11.5L, PH, TAPPING, BLK
(TWIDDLER SCREWS)
757326-011S 32
6 TWIDDLER 2.5IN NEO TXX SERV 742631-001S 8
7 COVER, ARRAY, MH, SERV 625273-011S 2
8 ASSY, POSITIONING MAGNET, SERV 628066-001S 2
9 BAFFLE, WOOFER - 1 2
10 PCB ASSY, HALL AFFECT SENSOR, SVCE 724412-001S 2
11 WOOFER, 12IN, MH, SERV 625260-001S 1
12 GASKET, ENCLOSURE, MAIN, SERV 625294-011S 1
13 BRACKET, INTERNAL, MID-HIGH - 4
14 COVER, SMPS, RIGHT - 1 2, 3
15 COVER, SMPS, LEFT - 1 2, 3
16 HANDLE RECESS - 1 2
17 GASKET, ENCLOSURE, RIGHT - 1 2
18 GASKET, ENCLOSURE, LEFT - 1 2
19 HANDLE, UPPER - 1 2
20 INSERT, UPPER HANDLE - 2 2, 3
21 GASKET, ENCLOSURE, UPPER REAR - 1 2
22 GASKET, SMPS ACCESS PANEL, SVCE 628600-001S 1
23 PCB ASSY, MAGIC BOX, SMPS, SVCE 628476-001S 1 1
24 PCB ASSY, I/O-DSP, SVCE 628478-001S 1 1
25 GASKET, I/O PANEL, SVCE 628597-001S 1
26 HANDLE, REAR, MH, SVCE - 1 2
27 STAND, MOUNT INTERFACE, MH, SERV 625295-011S 1
28 GASKET, STAND MOUNT INTERFACE, SVCE 628346-001S 1
29 FOOT, FRONT RIGHT, MH, SERV 625288-012S 1
30 FOOT, FRONT LEFT, MH, SERV 625288-011S 1
31 SCREW, FOOT, M4X25 721717-001S 2
32 PCB, LED, MH 721366-001S 1
33 LIGHT GUIDE, LED, SVCE 720414-001S 3
34 LENS, LED, SVCE 720413-001S 1
35 BAFFLE, ARRAY - 2 2
- PANEL, I/O, MH, SERV 625277-011S 1
- KNOB, VOLUME, SERV 720516-011S 2
- SLIDE, SWITCH CAP, SERV 720517-011S 3
- LIGHT GUIDE, LED, /I/O, SERV 720518-001S 3
- PANEL SMPS, MH, SERV 625275-011S 1
- WIRE HARNESS, DSP, SVCE 744262-001S 1
- WIRE HARNESS, IEC/SMPS, SVCE 744260-001S 1 3
- WIRE HARNESS, WOOFER 747424-001S 1
- POWER SWITCH (AC POWER) 317373-000S 1 3
