Bose F1 812 Service Manual

20
Figure 3. F1 Model 812 Flexible Array Loudspeaker
1
1
2
3
5
6
7
35
4
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
26
25
28
27
29
30
2x 31
13
32
33
34
8
MAIN PART LIST (CONT.)
F1 Model 812 Flexible Array Loudspeaker (refer to Figure 3)
Item
Number
Description Part
Number
Qty. Note
- SHRINK TUBE, AC SWITCH 753068-001S 1 3
- SHRINK TUBE, AC INLET 753069-001S 1

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
