14
Specifications
F1 Subwoofer
System Performance
System Type Self powered
Frequency Response (–3 dB) 40 Hz – 250 Hz
Frequency Range (–10 dB) 38 Hz – 250 Hz
Nominal Dispersion Omni-directional
Maximum SPL @ 1 m 130 dB SPL (peak 6 dB CF)
Crossover Frequency 40 – 100 Hz Butterworth Bandpass, 100 Hz 4th order Butterworth HPF at Line Out
System Power 1000 W
Distortion at Rated Power 0.1 % Max (30 Hz - 15 kHz)
System Limiter Dynamic limiter
Power Indicator Blue LED: system on
Transducers
Driver Compliment 2 x 10" high-excursion drivers
Channels
Channels 1/2
Signal Indicators POWER/FAULT, LIMIT, FRONT LED, SIGNAL INPUT
Input Connections 2 XLR - 1/4" Combo
Controls Volume level, Front LED function select, Power on/off, Polarity select, Line output EQ
Additional Connections
Line Output XLR balanced
AC Mains IEC Connector
Physical
Enclosure Wood cabinet with high impact composite end caps
Grille Powder-coated perforated steel grille
Dimensions 27” H x 16.1” W x 17.6” D (688 x 410.16 x 448.5mm)
Net Weight 55 lbs (24.9 kg)
Power Supply Voltages
Universal AC power rating: 100-240 V 50 / 60 Hz +/- 20 %, 200 W max
