Bose F1 812 Service Manual

24
ELECTRICAL PART LIST
Resistors (continued)
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R76 GP, CHIP, RES., 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R77 CHIP, RES, 56K, OHM, 1%, 1/4W, 1206 QCF041010-5602
R78 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R79 CHIP, RES, Anti-Surge, 8.2 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-8208
R80 GP, CHIP, RES., 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R81 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R84 CHIP, RES, 220K OHM, 1/4W, 1%, 1206 QCF041010-2203
R85 CHIP, RES., 22 OHM, 1/4W, 1%, 1206 QCF041010-2209
R86 CHIP, RES., 22 OHM, 1/4W, 1%, 1206 QCF041010-2209
R87 GP, CHIP, RES., 20 OHM, 1/10W, 1%, 0603 QCF011030-2009
R88 GP, CHIP, RES., 150, OHM, 1%, 1/10W, 0603 QCF011030-1500
R89 GP, CHIP, RES., 15K OHM, 1%, 1/10W, 0603 QCF011030-1502
R91 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603, 1K,
OHM
QCF011030-1001
R92 CHIP, RES, 3.6M, OHM, 1%, 1206,
WK12V3604FTL,WALSIN, 1/4W, 500V
QCF041011-3604
R93 CHIP, RES, 150K OHM, 1/10W, 1%, 0603 QCF011030-1503
R97 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603, 1K,
OHM
QCF011030-1001
R98 CHIP, RES, 11K OHM, 1%, 1/10W, 0603 QCF011030-1102
R100 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R101 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R102 GP, CHIP, RES., 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R104 CHIP, RES, 56K, OHM, 1%, 1/4W, 1206 QCF041010-5602
R105 CHIP, RES, Anti-Surge, 2 OHM, 5%, 1/8W,
0805,WK08S, WALSIN
QCF085021-2008
R106 CHIP, RES., 1%, 1W, 499 OHM, 2512 QCF101250-4990
R107 CHIP, RES., 6.49K OHM, 1%, 1/10W, 0603 QCF011030-6491
R108 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R109 CHIP, RES, 3K OHM, 1/10W, 1%, 0603 QCF011030-3001
R110 CHIP, RES, 0.01 OHM, 1%, 1W, 1206,
WW12RR010FT, Walsin
QCF101010-1006 3
R111 CHIP, RES, Anti-Surge, 8.2 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-8208
R112 CHIP, RES, 680 OHM, 1/10W, 1%, 0603 QCF011030-6800
R113 GP, CHIP, RES., 5.6K OHM, 1/10W, 1%, 0603 QCF011030-5601
R114 CHIP, RES., 22 OHM, 1/4W, 1%, 1206 QCF041010-2209
R116 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R118 CHIP, RES, Anti-Surge, 2 OHM, 5%, 1/8W,
0805,WK08S, WALSIN
QCF085021-2008
R119 CHIP, RES., 22 OHM, 1/4W, 1%, 1206 QCF041010-2209
R120 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R122 GP, CHIP, RES., 8.2K OHM, 1/10W, 1%, 0603 QCF011030-8201
R123 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R125 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R126 GP, CHIP, RES., 2.2K OHM, 1/10W, 1%, 0603 QCF011030-2201
R127 GP, CHIP, RES., 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R130 CHIP, RES., 432 OHM, 1%, 1/10W, 0603 QCF011030-4320
R133 H/I, RESISTOR, 10 OHM, 5%, 1W QVF105000-1000
R135 CHIP, RES, 56K, OHM, 1%, 1/4W, 1206 QCF041010-5602
