Bose F1 812 Service Manual

39
ELECTRICAL PART LIST
Resistors (continued)
F1 Model 812 Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R23 CHIP, RES, 20 OHM, 1%, 1/8W, 0805 QCF081020-2009
R24 CHIP, RES, 20 OHM, 1%, 1/8W, 0805 QCF081020-2009
R25 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R26 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R27 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R28 CHIP, RES, 270 OHM, 1/10W, 1%, 0603 QCF011030-2700
R29 CHIP, RES, 270 OHM, 1/10W, 1%, 0603 QCF011030-2700
R30 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R31 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R32 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R33 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R34 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R35 GP, CHIP, RES, 470 OHM, 1/8W, 1%, 0805 QCF081020-4700
R36 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R37 GP, CHIP, RES, 33K OHM, 1/10W, 1%, 0603 QCF011030-3302
R38 GP, CHIP, RES, 12K OHM, 1%, 1/10W, 0603 QCF011030-1202
R39 GP, CHIP, RES, 470 OHM, 1/8W, 1%, 0805 QCF081020-4700
R40 CHIP, RES, 33.2K OHM, 1%, 1/10W, 0603 QCF011030-3322
R41 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R42 GP, CHIP, RES, 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R43 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R44 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R45 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R46 GP, CHIP, RES, 1.5K OHM, 1%, 1/10W, 0603 QCF011030-1501
R47 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R48 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R49 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R50 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R51 CHIP, RES, 14K OHM, 1%, 1/10W, 0603 QCF011030-1402
R52 GP, CHIP, RES, 1/10W, 1%, 100 OHM, 0603 QCF011030-1000
R53 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R54 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R55 CHIP, RES, 33.2K OHM, 1%, 1/10W, 0603 QCF011030-3322
R56 GP, CHIP, RES, 2K OHM, 1/10W, 1%, 0603 QCF011030-2001
R57 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R58 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R59 GP, CHIP, RES, 1/10W, 1%, 100 OHM, 0603 QCF011030-1000
R60 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R61 CHIP, RES., 51 OHM, 1%, 1/10W, 0603 QCF011030-5109
R62 CHIP, RES., 51 OHM, 1%, 1/10W, 0603 QCF011030-5109
R63 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R64 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R65 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R66 CHIP, RES., 470 OHM, 1/10W, 1%, 0603 QCF011030-4700
R67 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R68 GP, CHIP, RES, 18K OHM, 1/10W, 1%, 0603 QCF011030-1802
R69 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R70 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R71 GP, CHIP, RES., 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
R72 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R73 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R74 GP, CHIP, RES, 4.7K OHM, 1/10W, 1%, 0603 QCF011030-4701

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
