Bose F1 812 Service Manual

59
ELECTRICAL PART LIST
Diodes (continued)
Reference
Designator
Description
V
endor Part
Number
Note
D13 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80,
SMT TYPE
RCD104148-1010
D14 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80,
SMT TYPE
RCD104148-1010
D15 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D16 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D17 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D18 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D19 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D20 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D21 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D22 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D23 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80,
SMT TYPE
RCD104148-1010
D24 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D25 DIODE, SW, BAV99, DIODES INC, SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D27 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80,
SMT TYPE
RCD104148-1010
Transistors
Reference
Designator
Description
V
endor Part
Number
Note
Q1 CHIP, XISTR, 3P, PNP, MMBT3906, SOT23 RCP003906-0002
Q2 CHIP, XISTR, 3P, PNP, MMBT3906, SOT23 RCP003906-0002
Q3 XISTR, NPN, MMBT3904, SOT-23, LRC, NPN,
GENERAL, PURPOSE, AMPLIFIER
RCN003904-0008
Q4 XISTR, NPN, MMBT3904, SOT-23, LRC, NPN,
GENERAL, PURPOSE, AMPLIFIER
RCN003904-0008
Q5 XISTR, NPN, MMBT3904, SOT-23, LRC, NPN,
GENERAL, PURPOSE, AMPLIFIER
RCN003904-0008
Q6 XISTR, NPN, MMBT3904, SOT-23, LRC, NPN,
GENERAL, PURPOSE, AMPLIFIER
RCN003904-0008
Q11 XISTR, PNP, KST92, SOT-23 RCP000092-0001
Q12 XISTR, NPN, MMBT3904, SOT-23, LRC, NPN,
GENERAL, PURPOSE, AMPLIFIER
RCN003904-0008
Q15 COMPOSITE TRANSISTOR, SOT-363, MMDT4413 RCC004413-0010
Q16 COMPOSITE TRANSISTOR, SOT-363, MMDT4413 RCC004413-0010
Q18 XISTR, NPN, MMBT3904, SOT-23, LRC, NPN,
GENERAL, PURPOSE, AMPLIFIER
RCN003904-0008
Q19 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
Q20 CHIP, MOSFET, 2N7002, SOT-23, N-CHANNEL RCM207002-1001
F1 Subwoofer Input-Output / DSP PCB Assembly

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
