Bose F1 812 Service Manual

61
ELECTRICAL PART LIST
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
CON1 XLR Connector, 6P, NCJ6FAV-0, 25*25*24MM CJDA06401-1010
CON2 XLR Connector, 3P, NC3MAAV, 19.8*9.8*24MM CJDA03401-1010
CON3 XLR Connector, 6P, NCJ6FAV-0, 25*25*24MM CJDA06401-1010
CON4 XLR Connector, 3P, NC3MAAV, 19.8*9.8*24MM CJDA03401-1010
J1 CONNECTOR, 3 PIN, P=2.5, White, 90', Normal CCN250000-0503
J2 CONNECTOR, PITCH=2.0mm, 3 PIN, 90', RE CCN200010-0503
J3 CONNECTOR, 10 PIN, P=2.5, White, 90', Normal CCN250000-0510
SW1 SLIDE, SWITCH, 2P/2T, SS-22F20, 17*7.5MM MSWA04018-0010
SW2 SLIDE, SWITCH, 2P/2T, SS-22F20, 17*7.5MM MSWA04018-0010
SW3 SLIDE, SWITCH, 2P/3T, SS-23E03, 20*9.3MM MSWA04017-0010
SW4 SMD, TACT, SWITCH, SOY-164BST MCWA06011-0010
VR1 POT, ROTARY, 10k OHM, RV09BCF-40-25F-B10K-
0C, 12 O'CLOCK POSITION WITH CENTER
DETENT
MVRA02101-1031
Y1 CRYSTAL, CITIZEN: CM309S24.576MABJTR,
30ppm, 24.576MHZ, L12.5XW4.6XH3.7MM
JCQ003001-2461
- Knob, Volume, TPE, natural, black, H19xOD12 BPKA05082-0001
- Slide Switch Cap, ABS, Kingfa GAR, L20xW19xH9 BPOA00090-0001
- Light Guide, LED, /I/O, PC+5%, TiO,
L29.6xW16.8xH7.3
BPSA02086-0001
- DSP Panel, Aluminum, 1050, painted,
L201.15xW147.5xH242xT3
GALA00626-0001
- DSP Gasket, EVA, 38degree, Natural Black,
L200.55xW14.5xT2
IVEA00727-0001
- DSP Gasket, EVA, 38degree, Natural Black,
L125.9xW8xT2
IVEA00727-0002
- SCREW, M3x0.5PxL8mm, NICKEL PLATED, PAN
HEAD
HSPA43083-1080
- Screw, T3.0x1.058PxL10, Zinc+CED Coating, PAN
HEAD, TYPE B, FREARSON SUS
HSPA50343-3100
F1 Subwoofer Input-Output / DSP PCB Assembly

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
