Bose FreeSpace IZA 190-HZ User Manual

English Installation and Operation Page 37
pro.Bose.com Specifications
Controls and Indicators
LED Status Indicators
Power - blue; Input Clip - red (-3 dBFS)
Controls, Front Panel
Power On/Off, Input Select (A/B), Tone Controls (Treble/Bass), Mic/Line Gain, Master Level
Controls, Rear Panel
Amplifier Mode DIP Switch, Loudspeaker EQ Preset Selector,
Input Gain (A/B/Page Mic), Output Trim
Electrical Specifications
Mains Voltage
100V AC - 240V AC (+ /- 10%, 50/60 Hz)
AC Power Consumption
15 W (Idle), 200 W (Max)
AC Mains Connector
Standard IEC (C14)
Peak Inrush Current
13.9 Amps (230V/50 Hz), 7.6 Amps (120V/60 Hz)
Overload Protection
High temperature, short
Physical
Rack Space Units
1 RU high, half rack wide
Dimensions
12.2" L x 8.4" W x 1.8" H (310 mm x 214 mm x 45 mm)
Shipping Weight
250-LZ: 6.7 lb (3.0 kg), 190-HZ: 9.0 lb (4.1 kg)
Product Weight
250-LZ: 4.8 lb (2.2 kg), 190-HZ: 7.0 lb (3.2 kg)
Cooling System
Natural convection
General
Inputs (Control)
Remote input for Volume Control with A/B Select User Interface,
Mute input for amplifier muting via contact closure
Accessories
ZA 250-LZ zone amplifier, ZA 190-HZ zone amplifier,
Volume Control with A/B Select User Interface, Rack Mount Kit

Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
