Bose FreeSpace IZA 2120-LZ Service Manual

60
Capacitors
ELECTRICAL PART LIST
Resistors (continued)
FreeSpace IZA 2120-HZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R883 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R884 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R885 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R891 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R892 RMG, 1/16W, 1.5K, 1%, 0603 4723-152A+P-R
R893 RMG, 1/16W, 2.7K, 1%, 0603/1608 4723-272A+P
R894 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R895 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A+P
R896 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
Reference
Designator
Description
V
endor Part
Number
Note
C700 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C701 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C702 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C710 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C711 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C712 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C713 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C714 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C717 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C718 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C721 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C722 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C723 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C724 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C725 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C726 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C727 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C728 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C729 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C730 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C735 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C739 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C741 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C743 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C746 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C747 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C749 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C750 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C755 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C757 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C760 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C761 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C762 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C765 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C767 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C768 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-102J+J-BDM
C769 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-102J+J-BDM
C771 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C772 CC, 50V, 22P, 5%, 0603, C0G 150F-220J+P-AC
