69
ELECTRICAL PART LIST
FreeSpace
®
ZA 2120-HZ Rear Panel PCB Assembly
Transistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
U708 IC, TL072CDR, DUAL, J-FET, INPUT, OP-AMP,
(SMD
3130-8020+0
U709 IC, TL072CDR, DUAL, J-FET, INPUT, OP-AMP,
(SMD
3130-8020+0
U710 IC, LM13700M/NOPB, TRANSCONDUCTANCE,
AMP
3132-1981+0
U711 IC, TL072CDR, DUAL, J-FET, INPUT, OP-AMP,
(SMD
3130-8020+0
U712 IC, 2CH, VOLUME, BD3812F, SOP14 3132-6071+0
U713 IC, TL072CDR, DUAL, J-FET, INPUT, OP-AMP,
(SMD
3130-8020+0
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J401 5P, ST., WAFER, P=2.0, COULOMB 2102-050S+003
J402 WIRE-CONN, 6P, P2.0, #28, UL1007, L=480,
RD/WH, F/M
7013-4530+0
J403 WIRE-CONN, 4P, P2.0, #28, UL1007, L=230,
RD/WH, F/M
7013-4540+0
J404 WIRE-CONN, 7P, P2.0, #28, UL1007, L=140,
RD/WH, F/M
7013-4520+0
J405 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361+1
J406 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361+1
J407 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361+1
J700 RCA, JACK, F, 2P, P15, 30V, 0.3A, H=10+9.5, R/W 2113-3153+2
J701 CONN, FFC, 10P, P0.5, SMT, ST, F 2101-3375+1
J702 SOCKET, M, 5P, P5, 250V, 12A, GRN, ST 2113-3421+0
SW400 SWITCH, SLIDE, DPDT, 50V, 0.5A, L=7 5200-5012+0
SW401 SWITCH, SLIDE, DPDT, 50V, 0.5A, L=7 5200-5012+0
SW700 SWITCH, SLIDE, DPDT, 50V, 0.5A, L=7 5200-5012+0
SW701 SWITCH, SLIDE, DPDT, 50V, 0.5A, L=7 5200-5012+0
VR400 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH,
CTR
4751-226E+0
VR401 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH,
CTR
4751-226E+0
