89
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-LZ DSP Front Panel Assembly
Resistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
R928 RMG, 1/16W, 1R, 5%, 0603 4723-1R0J
R929 RMG, 1/16W, 1R, 5%, 0603 4723-1R0J
R930 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R931 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
C900 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C901 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C902 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C903 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C904 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C905 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C906 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C907 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C908 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C909 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C910 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C911 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C912 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C913 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C914 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C915 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C916 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C917 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C918 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C919 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C920 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C921 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C922 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C923 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C924 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C925 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C926 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C927 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C928 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C929 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C930 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C931 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C932 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
Reference
Designator
Description
V
endor Part
Number
Note
D900 DIODE, BAV99, SOT23 4840-8970
D901 DIODE, BAV99, SOT23 4840-8970
D902 DIODE, BAV99, SOT23 4840-8970
D903 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0
D904 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0
Diodes
