Bose FreeSpace IZA 2120-LZ Service Manual

96
ELECTRICAL PART LIST
FreeSpace
®
IZA 2120-LZ Rear Panel PCB Assembly
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J701 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361+1
J702 RCA, JACK, F, 2P, P15, 30V, 0.3A, H=10+9.5, R/W 2113-3153+2
J703 RCA, JACK, F, 2P, P15, 30V, 0.3A, H=10+9.5, R/W 2113-3153+2
J704 RCA, JACK, F, 2P, P15, 30V, 0.3A, H=10+9.5, R/W 2113-3153+2
J705 SOCKET, EURO, BLOCK, 4P, P5, STRAIGHT,
GREEN
2113-3148+0
J707 SOCKET, SPEAKER, 4P, P5, 250V, 12A, BLACK 2113-3148+1
J711B CONNECTOR, PIN, HEADER, 4P, P2.54, ST, F 2101-3294+0
J712 SOCKET, M, 5P, P5, 250V, 12A, GRN, ST 2113-3421+0
J713 SOCKET, M, 5P, P5, 250V, 12A, GRN, ST 2113-3421+0
J717 CONN, HEADER, 12P, P2.54, DIP, ST, M, L=8.54 2101-3410+0
J718 CONN, HEADER, 12P, P2.54, DIP, ST, M, L=8.54 2101-3410+0
SW700 SW, SLIDE, 1P5T, DC50V, 0.5A 5200-5085+0
VR700 VR, ROTARY, 100KAX2, 20%, V, L=15, 18TEETH,
90C, CTR
4751-225E+1
VR701 VR, ROTARY, 100KAX2, 20%, V, L=15, 18TEETH,
90C, CTR
4751-225E+1
VR702 VR, ROTARY, 10K/10CX1, 20%, V, L=15,
18TEETH, CTR
4751-224E+0
VR704 VR, ROTARY, 10K/10CX1, 20%, V, L=15,
18TEETH, CTR
4751-224E+0
VR705 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH,
CTR
4751-226E+0
VR706 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH,
CTR
4751-226E+0
