POWER-AMP PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R46 RES, THICK FILM, 0603, 0.1W, 1%, 133K 857326-0104
R47, R72, R79, R87 RES, THICK FILM, 0603, 0.1W, 1%, 100K 857326-0094
R48 RES, THICK FILM, 0603, 0.1W, 1%, 130K 857326-0103
R49-R51 RES, THICK FILM, 1206, 0.25W, 1%, 240K 857326-0205
R4-R6, R10-R12 RES, THICK FILM, 1206, 0.25W, 1%, 1M 857326-0198
R56, R69-R71 RES, THICK FILM, 1206, 0.25W, 1%, 2.2 OHM 857326-0214
R58-R59, R121, R125 RES, THICK FILM, 0603, 0.1W, 1%, 1.5K 857326-0108
R60 RES, THICK FILM, 0603, 0.1W, 1%, 470 OHM 857326-0154
R62, R113 RES, THICK FILM, 0805, 0.125W, 1%, 100
OHM
857326-0186
R63, R86, R265 RES, THICK FILM, 0603, 0.1W, 1%, 4.7K 857326-0155
R7, R28, R90, R92, R96,
R107
RES, THICK FILM, 0805, 0.125W, 5%, 4.7 OHM 857326-0194
R73 RES, THICK FILM, 0603, 0.1W, 1%, 7.5K 857326-0175
R74 RES, THICK FILM, 1206, 0.25W, 1%, 680 OHM 857326-0210
R76-R77 RES, THICK FILM, 0603, 0.1W, 1%, 2.2K 857326-0127
R8, R27, R52 RES, THICK FILM, 0805, 0.125W, 1%, 22 OHM 857326-0189
R80, R82 RES, THICK FILM, 0603, 0.1W, 1%, 100 OHM 857326-0091
R84-R85, R88 RES, THICK FILM, 1206, 0.25W, 1%, 20K 857326-0200
R91, R139, R264 RES, THICK FILM, 0603, 0.1W, 1%, 3.3K 857326-0144
R93, R112 RES, THICK FILM, 0603, 0.1W, 1%, 1M 857326-0095
R94, R98, R110, R115 RES, THICK FILM, 1206, 0.25W, 1%, 220 OHM 857326-0203
R95, R135, R140-R142 RES, THICK FILM, 0603, 0.1W, 1%, 1K 857326-0092
R97, R108 RES, THICK FILM, 0805, 0.125W, 1%, 33 OHM 857326-0190
Capacitors
Reference Designator Description Material Number Note
C101 CAP, C0G, 0603, 50V, 5%, 220pF, COMM 780788-221J1H
C132, C141, C225, C229,
C235, C258
CAP, X7R, 0402, 50V, 10%, 0.1uF, COMM 718866-104K1H
C213-C215, C222-C223,
C227, C246, C250-C252,
C259, C262
CAP, X7R, 0402, 100V, 10%, 2200pF, COMM 718866-222K2A
C216, C232, C242, C254 CAP, FILM, LS 5mm, AMMO, 5%, 100V, 1uF 329288-1004BJA
C217, C219, C231, C233,
C243, C245, C255, C257
CAP, X7R, 0805, 100V, 20%, 0.01uF, COMM 763872-103M2A
C218, C230, C244, C256 CAP, C0G, 0805, 100V, 5%, 1000pF, COMM 763940-102J2A
C224, C226, C247, C249 CAP, X7R, 0402, 50V, 10%, 0.033uF, COMM 718866-333K1H
C228, C239, C248, C263 CAP, EL, SMT, 105C, 16V, 20%, 10uF, COMM 856752-100M1CAB
