Bose L1 Pro8

30
POWER-AMP PCB PARTS LIST
Capacitors (continued)
Reference Designator Description Material Number Note
C234, C238, C253, C260 CAP, C0G, 0402, 50V, 5%, 100pF, COMM 766718-101J1H
C236-C237 CAP, X5R, 0402, 16V, 10%, 1uF, COMM 716994-105K1C
C26 CAP, FILM, PFC, 15mm, BULK 6mm, 630V,
10%, 1uF
856507-105K2JBB
C261 CAP, X7R, 0402, 25V, 10%, 0.047uF, COMM 718866-473K1E
C275-C276, C278-C279 CAP, X7R, 0805, 100V, 10%, 0.1uF, COMM 763872-104K2A
C29-C30 CAP, X7R, HI VOLT, 0805, 630V, 10%, 4700pF,
COM
852020-472K2J
C31 CAP, EL, SNAP-IN, 450V, 20%, 330uF 853707-331M2WCC
C35-C36 CAP, C0G, 0603, 50V, 5%, 47pF, COMM 780788-470J1H
C40, C42-C43, C58-C59,
C61, C68, C79, C91-C93,
C95, C108-C109
CAP, C0G, 0603, 50V, 5%, 1000pF, COMM 780788-102J1H
C41, C85 CAP, C0G, 0603, 50V, 5%, 330pF, COMM 780788-331J1H
C45, C48-C51, C80 CAP, X7R, 0805, 25V, 10%, 1uF, COMM 763872-105K1E
C46 CAP, X7R, 0603, 100V, 10%, 220pF, COMM 718875-221K2A
C47, C69-C70, C75 CAP, X7R, HI V, 1206, 1000V, 10%, 4700pF,
COMM
852057-472K3A
C52-C53 CAP, EL, LOW Z, SMT, 35V, 20%, 470uF,
COMM
856727-471M1VEF
C55 CAP, EL, POLYMER, SMT, 25V, 20%, 47uF,
COMM
857020-470M1EAA
C60 CAP, X7R, 0603, 50V, 10%, 0.047uF, COMM 718875-473K1H
C62, C64-C65, C110-C111,
C113-C116, C284-C285
CAP, X7R, 0603, 100V, 10%, 0.1uF, COMM 718875-104K2A
C73 CAP, X7R, 0603, 50V, 10%, 1uF, COMM 718875-105K1H
C76-C77 CAP, X7R, HI V, FT, 1210, 500V, 10%, 0.1uF,
COMM
852058-104K2H
C78 CAP, X7R, 0603, 50V, 10%, 0.47uF, COMM 718875-474K1H
C8, C17, C39, C97 CAP, X7R, 0603, 50V, 5%, 10000pF, COMM 718875-103J1H
C83, C100 CAP, C0G, 0805, 250V, 5%, 100pF, COMM 763940-101J2E
C84, C86 CAP, X7R, HI VOLT, 0805, 500V, 10%, 470pF,
COMM
852020-471K2H
C89-C90, C267-C274 CAP, X7R, 0805, 100V, 10%, 0.47uF, COMM 763872-474K2A
C94 CAP, C0G, HI VOLT, 1206, 500V, 5%, 15pF,
COMM
777098-150J2H
C96 CAP, FILM, HI V, 15mm, BULK, 1000V, 5%,
0.68uF
856510-683J3ABB
C99, C134 CAP, X7R, 0603, 50V, 10%, 0.22uF, COMM 718875-224K1H
CX1-CX2 CAP, FILM, X2, LS 15mm, 305VAC, 20%,
0.47uF
310415-474MG 3
CY1-CY5 CAP, CER, X1/Y1, Bulk 25mm, 10%, 470pF 855444-471KG 3
CY6 CAP, CER, X1/Y1, Bulk 5mm, 20%, 1000pF 855444-102MN 3
