Bose PowerShare PS602 Service Manual

22
ELECTRICAL PART LIST
Resistors (continued)
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
R202 0603, .1W, 1%, 1K 191465-1001
R203 0805, .125W, 1%, 49.9K 133625-4993
R204 0603, .1W, 1%, 1K 191465-1001
R205 0603, .1W, 1%, 3.09K 191465-3091
R206 0603, .1W, 1%, 1K 191465-1001
R207 0805, .125W, 1%, 49.9K 133625-4993
R208 0805, .125W, 1%, 49.9K 133625-4993
R209 0603, .1W, 1%, 3.09K 191465-3091
R210 0603, .1W, 1%, 3.09K 191465-3091
R211 0603, .1W, 1%, 3.09K 191465-3091
R212 0603, .1W, 1%, 2.15K OHM 191465-2151
R213 0603, .1W, 1%, 2.15K OHM 191465-2151
R214 0603, .1W, 1%, 14.7K 191465-1472
R215 0603, .1W, 1%, 14.7K 191465-1472
R216 0603, .1W, 1%, 14.7K 191465-1472
R217 0603, .1W, 1%, 14.7K 191465-1472
R218 0603, .1W, 1%, 30.1K 191465-3012
R219 0603, .1W, 1%, 30.1K 191465-3012
R220 0603, 0.1W, 1%, 1.30K 191465-1301
R221 0603, 0.1W, 1%, 1.30K 191465-1301
R222 0603, 0.1W, 1%, 1.30K 191465-1301
R223 0603, .1W, 1%, 24.9 OHM 191465-24R9
R224 0603, .1W, 1%, 24.9 OHM 191465-24R9
R225 0603, 0.1W, 1%, 1.30K 191465-1301
R226 0603, .1W, 1%, 30.1K 191465-3012
R227 0603, .1W, 1%, 30.1K 191465-3012
R228 0603, .1W, 1%, 2.0K 191465-2001
R229 0603, .1W, 1%, 2.0K 191465-2001
R230 0603, 0.1W, 1%, 374 OHMS 191465-3740
R231 0603, 0.1W, 1%, 374 OHMS 191465-3740
R232 0603, 0.1W, 1%, 976 OHMS 191465-9760
R233 0603, .1W, 1%, 1K 191465-1001
R234 0603, 0.1W, 1%, 976 OHMS 191465-9760
R235 0603, .1W, 1%, 1.4K 191465-1401
R236 0603, .1W, 1%, 1.4K 191465-1401
R237 0603, .1W, 1%, 1K 191465-1001
R238 0603, .1W, 1%, 1K 191465-1001
R239 MR, 0603, 25ppm/C, 0.1W, 0.1%, 2K 765579-2001B
R240 0603, .1W, 1%, 1K 191465-1001
R241 MR, 0603, 25ppm/C, 0.1W, 0.1%, 2K 765579-2001B
R242 0603, 100MW, 1%, 3.40 K 191465-3401
R243 MR, 0603, 25ppm/C, 0.1W, 0.1%, 2K 765579-2001B
R244 0603, 100MW, 1%, 3.40 K 191465-3401
R245 MR, 0603, 25ppm/C, 0.1W, 0.1%, 2K 765579-2001B
R246 MR, 0603, 25ppm/C, 0.1W, 0.1%, 2K 765579-2001B
R247 0603, .1W, 1%, 100K 191465-1003
R248 MR, 0603, 25ppm/C, 0.1W, 0.1%, 2K 765579-2001B
R249 MR, 0603, 25ppm/C, 0.1W, 0.1%, 2K 765579-2001B
R250 MR, 0603, 25ppm/C, 0.1W, 0.1%, 2K 765579-2001B
R251 0603, 100MW, 1%, SMD, 825 OHM 191465-8250
R252 0603, .1W, 1%, 422 OHMS 191465-4220
R253 MR, 0805, 25ppm/C, 0.25W, 0.1%, 26.7K 765580-2672B
