Capacitors
ELECTRICAL PART LIST
Rear Output PCB Assembly, PS602P
Inductors
Reference
Designator
Description
endor Part
Number
Note
L950 CHOKE, COMMON, MODE, 40U, 10%, 10A, TC1305,
MI
1805-0450
L951 CHOKE, COMMON, MODE, 40U, 10%, 10A, TC1305,
MI
1805-0450
Integrated Circuits
Reference
Designator
Description
endor Part
Number
Note
U710 IC, ESD PROTECTION, TPD2E001, SOT533 3132-7831
Miscellaneous
Reference
Designator
Description
endor Part
Number
Note
ENCODER702 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10,
COPAL
5200-509727
ENCODER703 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10,
COPAL
5200-509727
J711A CONNECTOR, PIN, HEADER, 4P, P2.54, ST, M,
L=15
2101-3295
J714 USB-B, CONN, F, 4PIN, P2.5, 30V, 1.5A, 12X11, SIL 2113-3428
J951 WIRE-CONN, 4P, P3.96, #18, UL1007, L=300, F/M,
FERRITE
7013-5270
J964 SPEAKON, F, 4P, 250V, 30A, 31X26X24, BK,
NL4MD-H-2, H
2113-3418
J965 SPEAKON, F, 4P, 250V, 30A, 31X26X24, BK,
NL4MD-H-2, H
2113-3418
J966 CONNECTOR, 2P, P3.96, STRAIGHT, M 2101-2780
J967 CONNECTOR, 2P, P3.96, STRAIGHT, M 2101-2780
SW702 SW, DIP, SPST, 24V, 25MA, P2.54, 6P 5200-5077
Reference
Designator
Description
endor Part
Number
Note
C950 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C951 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C952 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C953 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C954 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C955 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C956 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C957 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C958 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C959 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C960 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C961 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C962 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C963 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C964 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C965 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C966 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C967 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
C968 CC, 630V, 1000pF, 10%, 1206 150M-102KCF
