ELECTRICAL PART LIST
Diodes (continued)
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
D309 SCHOTTKY, 1A, 30V, SOD123 317122-001
D310 SCHOTTKY, 1A, 30V, SOD123 317122-001
D311 SCHOTTKY, 1A, 30V, SOD123 317122-001
D312 SCHOTTKY, 1A, 30V, SOD123 317122-001
D313 SCHOTTKY, 1A, 30V, SOD123 317122-001
D314 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D315 SCHOTTKY, 1A, 30V, SOD123 317122-001
D316 SCHOTTKY, 1A, 30V, SOD123 317122-001
D317 SCHOTTKY, 1A, 30V, SOD123 317122-001
D318 SCHOTTKY, 1A, 30V, SOD123 317122-001
D319 SCHOTTKY, 1A, 30V, SOD123 317122-001
D320 SCHOTTKY, 1A, 30V, SOD123 317122-001
D321 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D322 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D323 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D324 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D325 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D326 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D327 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D328 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D400 SCHTKY, SC70, 30V, SINGLE 268381-001
D401 SCHTKY, SC70, 30V, SINGLE 268381-001
D402 SCHTKY, SC70, 30V, SINGLE 268381-001
D403 SCHTKY, SC70, 30V, SINGLE 268381-001
D404 SCHOTTKY, 1A, 30V, SOD123 317122-001
D405 SCHOTTKY, 1A, 30V, SOD123 317122-001
D406 SCHOTTKY, 1A, 30V, SOD123 317122-001
D407 SCHOTTKY, 1A, 30V, SOD123 317122-001
D408 SCHOTTKY, 1A, 30V, SOD123 317122-001
D409 SCHOTTKY, 1A, 30V, SOD123 317122-001
D410 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D411 SCHOTTKY, 1A, 30V, SOD123 317122-001
D412 SCHOTTKY, 1A, 30V, SOD123 317122-001
D413 SCHOTTKY, 1A, 30V, SOD123 317122-001
D414 SCHOTTKY, 1A, 30V, SOD123 317122-001
D415 SCHOTTKY, 1A, 30V, SOD123 317122-001
D416 SCHOTTKY, 1A, 30V, SOD123 317122-001
D417 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D418 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D419 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D420 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D421 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D422 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D423 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D424 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
ZR100 ZENER, 10.V, 225MW, 5%, SOT-23 135247-5240
ZR101 ZENER, 10.V, 225MW, 5%, SOT-23 135247-5240
ZR200 ZENER, 5.6V, 250mW, 1%, SOT-23 135247-1232
ZR201 ZENER, 5.6V, 250mW, 1%, SOT-23 135247-1232
ZR202 ZENER, 5.6V, 250mW, 1%, SOT-23 135247-1232
ZR203 ZENER, 5.6V, 250mW, 1%, SOT-23 135247-1232
ZR204 ZENER, 7.5V, 250mW, 1%, SOT-23 135247-1236
