Bose PowerShare PS602 Service Manual

41
ELECTRICAL PART LIST
Capacitors (continued)
SMPS PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description
V
endor Part
Number
Note
C218 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C219 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C220 CE, 100V, 2000uF, 20%, RL, 35X25, SNAP-105C 157H-208M^&T
C221 CE, 100V, 2000uF, 20%, RL, 35X25, SNAP-105C 157H-208M^&T
C225 CC, 500V, 0.022uF, 10%, 1206 150L-223KCF
C226 CC, 500V, 0.022uF, 10%, 1206 150L-223KCF
C227 CC, 630V, 0.1uF, 10%, 1812, X7R 150M-104KHF
C232 CC, 100V, 100pF, 10%, 0805, 1.2X2, NPO 150H-101KBD
C233 CC, 100V, 100pF, 10%, 0805, 1.2X2, NPO 150H-101KBD
C234 CC, 100V, 100pF, 10%, 0805, 1.2X2, NPO 150H-101KBD
C235 CC, 100V, 100pF, 10%, 0805, 1.2X2, NPO 150H-101KBD
C239 CE, 35V, 100uF, 20%, RLT, 6.3X11, 105C, LOW ESR 157Q-107MLUTR
C243 CC, 630V, 100pF, 5%, 1206, 3.2X1.6 150M-101JCF
C244 CC, 630V, 100pF, 5%, 1206, 3.2X1.6 150M-101JCF
C245 CC, 630V, 100pF, 5%, 1206, 3.2X1.6 150M-101JCF
C246 CC, 630V, 100pF, 5%, 1206, 3.2X1.6 150M-101JCF
C247 CC, 400V, 470pF, +20%, RL, 9.5X8.0, AH09B471KLO 150T-471MRO 3
C248 CC, 400V, 470pF, +20%, RL, 9.5X8.0, AH09B471KLO 150T-471MRO 3
C249 CE, 450V, 270uF, 20%, RL, 35X30, SNAP-105C 1574-277M^$T
C250 CE, 450V, 270uF, 20%, RL, 35X30, SNAP-105C 1574-277M^$T
C251 CP, 275V, 0.47uF, 20%, RB, 18X16 158Z-474M75 3
C252 CP, 275V, 0.47uF, 20%, RB, 18X16 158Z-474M75 3
C254 CC, 1000V, 2200pF, 10%, 1206, X7R 150N-222KCF
C255 CC, 1000V, 2200pF, 10%, 1206, X7R 150N-222KCF
C256 CC, 50V, 1500pF, 10%, 0805, 1.2x2.0 150F-152KBD
C257 CM, 400V, 0.47uF, 5%RB, 16X16, X7, METALLIZED,
FARATRONIC
153T-474J55M4 3
C259 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C260 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C261 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C262 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C263 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C264 CC, 50V, 2200pF, 5%, 0603, 0.8X1.6 150F-222JAC
C265 CC, 50V, 0.47uF, 10%, 0805, 1.25X2, X7R 150F-474KBD
C266 CC, 50V, 0.33uF, 10%, 0805
(NOT USED ON PS604)
150F-334KBD PS602
PS602P
C267 CE, 25V, 470uF, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C268 CE, 35V, 1000uF, 20%, RLT, 10X30, 105C-LESR 157Q-108MS$TR
C269 CE, 25V, 470uF, 20%, RLT, 10X16, 105C, RX,
NOVER
157E-477MS5TU
C270 CE, 35V, 1000uF, 20%, RLT, 10X30, 105C-LESR 157Q-108MS$TR
C271 CE, 35V, 100uF, 20%, RLT, 6.3X11, 105C, LOW,
ESR
157Q-107MLUTR
