Bose PowerShare PS602

75
ELECTRICAL PART LIST
Inductors
DSP PCB Assembly, PS602P
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D400 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A,
SMD, PANJIT
480S-K160+3
D401 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A,
SMD, PANJIT
480S-K160+3
D402 LED, SMD, 2.0X1.25X0.8, GN, SUPER, EVLITE 3700-7839+G
D403 LED, SMD, 2.0X1.25X0.8, RD, SUPER, EVLITE 3700-7839+R
D404 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D405 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D406 LED, SMD, 2.0X1.25X0.8, GN, SUPER, EVLITE 3700-7839+G
D407 DIODE, BAV99, SOT23, PHILIPS 4840-8970+3
D408 LED, SMD, 2.0X1.25X0.8, RD, SUPER, EVLITE 3700-7839+R
D410 DIODE, 1SS355TE-17, ROHM 4840-1660+0
D415 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0+3
D416 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0+3
D417 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0+3
D418 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0+3
Transistors
Reference
Designator
Description
V
endor Part
Number
Note
Q409 TR, KTA1504Y 4851-504Y+3
Q410 TR, PNP, 2SA2058, HFE:, 125, 2-3S1A, SM 4852-0580+3
Reference
Designator
Description
V
endor Part
Number
Note
L400 INDUCTOR, 22uH, 20%, 8.1X8, B1000AS-220M=P3,
SMD, TOKO
1803-0103+0
L401 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872+0
L402 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872+0
L403 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872+0
L404 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872+0
L405 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872+0
L406 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L407 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L408 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L409 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L410 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L411 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L412 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L413 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L414 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
L415 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878+0
