Main PCB Electrical Part List
Resistors (continued)
Reference Designator Description Vendor Part Number Note
R61, R62 CHIP, 51 OHM, 100PPM, +- 1%,
0402, WALS, L
T502510A01399 2
R65, R88, R91, R97, R169,
R201, R302, R303
CHIP, 47K OHM, 100PPM, +- 1%,
0402, WALS, L
T502470201399 2
R69, R74, R75, R84, R85, R92,
R93, R102
CHIP, 3.6K OHM, 100PPM, +-
1%, 0402, WALS, L
T502360101399 2
R70, R72, R78, R80, R86, R89,
R96, R100, R214
CHIP, 5.6K OHM, 100PPM, +-
1%, 0402, WALS, L
T502560101399 2
R71, R73, R79, R81, R87, R90,
R99, R101
CHIP, 180 OHM 100PPM +-1%
0402 WALS L
T502180001399 2
R104, R344 CHIP, 1M OHM, 100PPM, +- 1%,
0402, WALS, L
T502100401399 2
R105, R114, R115, R127, R140 CHIP, 7.5K OHM,100PPM, +- 1%,
0402, WALS, L, WR04X7501FTL
T502750101399 2
R108, R111, R121, R123 CHIP, 470 OHM, 100PPM, +- 1%,
0402, WALS, L
T502470001399 2
R117 CHIP, 2M OHM, 100PPM, +- 1%,
0402, WALS, L
T502200401399 2
R118 CHIP, 453K OHM, 100PPM, +-
1%, 0402, WALS, L
T502453301399 2
R119, R195, R228 CHIP, 100K OHM, 100PPM, +-
1%, 0603, WALS, L
T502100302399 2
R124 CHIP, 390K OHM, 100PPM, +-
1%, 0402, WALS, L
T502390301399 2
R129 CHIP, 4.7 OHM, 100PPM, +- 5%,
1206, WALS, L
T502047A04499 2
R159 CHIP, 0 OHM, 1206, WALS, L T502000004499 2
R161 CHIP, 10 OHM, 100PPM, +- 1%,
0805, WALS, L
T502100A03399 2
R163, R258, R259, R262 CHIP, 300K OHM, 100PPM,
+- 1%, 1206, WALS, L, WR12X-
3003FTL
T502300304399 2
R167 CHIP, 10K OHM, 100PPM, +- 1%,
0805, WALS, L
T502100203399 2,3
R168 CHIP, 24K OHM, 100PPM, +- 1%,
0603, WALS, L, WR06X2402FTL
T502240202399 2
R171, R210, R516, R517 CHIP, 220 OHM, 100PPM, +- 1%,
0603, WALS L, WR06X2200FTL
T502220002399 2
R177 CHIP, 510 OHM, 100PPM, +- 1%,
0603, WALS, L
T502300302399 2
R179 CHIP, 300K OHM, 100PPM, - 1%,
0603 WALS, L, WR06X3003FTL
T502510002399
2
R180 CHIP, 91K OHM, 100PPM, +- 1%,
0603, WALS, L, WR06X9102FTL
T502910202399 2
R184, R313, R314, R9, R24,
R51, R52
CHIP, 10K OHM, 100PPM, +- 1%,
0603, WALS, L
T502100202399 2
