Item
Number
Description Part Number Qty Note
1 KNOB, TREBLE/BASS, 12mm DIA, SVCE 787967-011S 4
2 KNOB, REVERB, 10mm, DIA, SVCE 787968-011S 2
3 PANEL, I/O, SVCE 789257-011S 1
4 KNOB, VOLUME, 16mm DIA, SVCE 787966-011S 3
5
SWITCH, ROCKER, 3 POS, SVCE 788190-011S 1 3
6
ASSY, PCB, SWITCH 789259-001S 1 3
7 SLIDE SWITCH CAP 720517-011S 1
8 LIGHTPIPE, ROW OF 3 789264-0010 3
9 ASSY, PCB, CONTROL 788193-001S 1
10 BUTTON, BLUETOOTH, SVCE 789267-001S 1
11 HOLDER, BLUETOOTH BUTTON, 00.4 793939-0110 1
12
ASSY, PCB, MAIN
Note: Order items 10 and 11 when
replacing the ASSY, PCB, MAIN
788189-003S 1
13 GASKET, EDGE, PCB 797099-0110 1
Input Panel Assy
Refer to gure 3
