20
Main PCB Electrical Part List
Reference Designator Description Vendor Part Number Note
F1 FUSE, DIP, FUSE, 250V, 5A,
8X8.5, 39215, K, 39215000000
T690100003600 2,3
LED3 19-217\T1D-APQHY\3T T575003410202 2
J1A, JTW, JWF
CONNECTOR, 2P, P:2.0MM, 90ｰ,
SMT, K, PH-2AT-JK
T690300109100 2
J2A HOUSING, DUAL, PIN,
2*3PIN, 2.54MM, DIP, 180, K,
2.54Y-2X3P-11.5
T690300110100 2
J3 6.35MM, JACK, SOCKET, PLAS-
TIC, BLACK, K, CK6.35-3-14-
18LF
T690300121700 2
J4, J5 COMBO, JACK, RCJ9FI-V-0,
REAN, K, RCJ9FI-V-0
T710200010000 2
J6A CONNECTER, 11PIN, P=2.54,
DIP180ｰ, K, TJC3-11A-CS
T690300109800 2
J8
2X4P, P:2.54MM, 90ｰ, DIP, K,
2.54-2X4AW-10.4
T690300110000 2
J9 CHIP, CONNECTOR, 6PIN,
P:1.5MM, 90, K, ZH-6AT-JK
T690300087900 2
J11 CONNECTOR, 2PIN, 3.96MM,
DIP, 180, K, VH-3A2-01
T690300109500 2,3
JD11A 11PIN, 1.5MM, SMT, 90, K, ZH-
11AT-JK
T690300109300 2
JWT1 CONNECTOR, TJC3-6A-CS, 6,
PIN, K, TJC3-6A-CS
T690300097400 2
J20 SMD, IPEX, CONNECTOR, K,
818000281
T690300035700 2
J33A CONNECTOR, 2PIN, 1.5MM,
SMT, 90, K, ZH-2AT-JK
T690300108700 2
J35 CONNECTOR, 6IN, 2.0MM, DIP,
180, K, PH-6A-CS
T690300108800 2
MOV1 MOV, 350VA, TVR14561KSY, DIP,
TKS, K, TVR14561KSY
T591000149300 2,3
PJ1 EARPHONE, JACK, K, CK3.5-
33C5
T710200010500 2
RT1 NTC, THERMISTOR, RES,
17*7.5MM, MF72-8D13, K, MF72-
8D13N
T710600007800 2,3
RT2 100K 0402, NTC, K, NCP15WF-
104F03RC
T710600016200 2
RT3 NTC, 10K OHM, 1%, 0603, MU-
RATA, K, NCP18XH103F03RB
T710600007400 2
SW1 TACT, SWITCH, 50MA, 12VDC,
KFC-801B-1.6-M, K, Y.15.
QC44.102
T670200002100 2,3
Miscellaneous
