Bose SoundDock 10 Service Manual

7
PACKAGING PART LIST
Figure 1. Packing Exploded View
Item
Number
Description Part Number QTY Note
1 LINE CORD, 120V, PDL, BLK
LINE CORD, 220V, EUR, BLK
LINE CORD, 230V, KOREA, BLK
LINE CORD, 230V, UKS, BLK
LINE CORD, 240V, AUS, BLK
262814-001
280135-001
311668-001
280138-001
284243-001
1
2 COMMITMENT LETTER 251001 1
3 SHEET, ADDRESS PAGE, BOSE 289347-001 1
4 OWNERS GUIDE, 3L, US
OWNERS GUIDE, 11L, EUR
OWNERS GUIDE, 6L, AP
314136
314137
314138
1
5 PERSONAL AUDIO INBOX BROCHURE 310403-001 1
6 REMOTE CNTRL, IR, BLK 322254-0100 1
7 PACKING, TRAY, TOP, 20.8X12.8X6.1 312286 1
8 SOUNDDOCK-10 DMS 120V SILVER - 1
9 PACKING, TRAY, BOT, 20.8X12.8X6.1 312287 1
10 CARTON, RSC, 20.94X12.94X12.25, US 312288 1
11 CARTON, DC, 4.12"X2.06"X1.56", BT 319496-0010 1
12 MODULE, BLUETOOTH, SOUNDDOCK10
(finished good accessory)
310840-0000 1
- UNIVERSAL, INSERT (shown on next page) 317402-0010 1
- I-DOCK, SUBASSY (shown on next page) 318058-001S 1
2
3
4
5
6
7
8
9
10
12
11
BlueTooth Receiver is
packaged with 230V
Euro systems only
1
Bose
®
SoundDock
®
10 Digital Music System
