Bose SoundDock 10 Service Manual

9
ELECTRICAL PART LIST
DSP PCB Assembly
Resistors
Reference
Designator
Description Part Number Note
R1000 5.11K, 0603, .1W, 1% 191465-5111 4
R1001 5.11K, 0603, .1W, 1%, 191465-5111 4
R1002 75 OHM, 0805, 1/10W, 5% 133626-7505 4
R1003 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R1004 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R1005 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R1100 51 OHM, 0603, 100MW, 5%, 199403-510 4
R1101 51 OHM, 0603, 100MW, 5%, 199403-510 4
R1102 51 OHM, 0603, 100MW, 5%, 199403-510 4
R1103 51 OHM, 0603, 100MW, 5%, 199403-510 4
R1104 51 OHM, 0603, 100MW, 5%, 199403-510 4
R1105 51 OHM, 0603, 100MW, 5% 199403-510 4
R200 4.99K, 0805, .125W, 1% 133625-4991 4
R201 4.99K, 0805, .125W, 1% 133625-4991 4
R202 4.99K, 0805, .125W, 1% 133625-4991 4
R203 4.99K, 0805, .125W, 1% 133625-4991 4
R204 1M , 0603, .1W, 1%, 191465-1004 4
R205 1M , 0603, .1W, 1%, 191465-1004 4
R206 1M , 0603, .1W, 1%, 191465-1004 4
R207 1M , 0603, .1W, 1%, 191465-1004 4
R208 14K, 0603, .1W, 1%, 191465-1402 4
R209 14K , 0603, .1W, 1% 191465-1402 4
R210 15K, 0603, .1W, 1% 191465-1502 4
R211 14K , 0603, .1W, 1% 191465-1402 4
R212 15K, 0603, .1W, 1% 191465-1502 4
R213 14K, 0603, .1W, 1%, 191465-1402 4
R214 15K, 0603, .1W, 1% 191465-1502 4
R215 15K, 0603, .1W, 1% 191465-1502 4
R217 15K, 0603, .1W, 1% 191465-1502 4
R218 15K, 0603, .1W, 1% 191465-1502 4
R219 47OHM, 0603, SMD, 100MW, 5% 199403-470 4
R220 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R221 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R222 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R223 15K, 0603, .1W, 1% 191465-1502 4
R224 15K, 0603, .1W, 1% 191465-1502 4
R225 1.00K, 0805, 1/10W, 5% 133626-1025 4
R233 JUMPER, CHIP, 0603 196042 4
R234 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R300 1.5KOHM, ARRAY, SMT, 50V, 5% 186433-1524 4
R301 130K, 0603, 100MW, 1% 191465-1303 4
R304 4.99K, 0805, .125W, 1% 133625-4991 4
R305 4.99K, 0805, .125W, 1% 133625-4991 4
R309 2K, 0603, .1W, 1% 191465-2001 4
R310 2K, 0603, .1W, 1% 191465-2001 4
R311 2.49K, 0603, .1W, 1% 191465-2491 4
R400 1K, 0603, .1W, 5% 199403-102 4
R401 22 OHMS, 0603, .1W, 5% 199403-220 4
R402 6.04K, 0603, .1W, 1% 191465-6041 4
R403 6.04K, 0603, .1W, 1% 191465-6041 4
R404 3.3K, 0603, .1W, 5% 199403-332 4
R405 20K, 0603, .1W, 5% 199403-203 4
R406 0.47 OHM, 1210, 500mW, 5% 318356-471J 4
R407 100 OHM, 1206, 1/4W, 1% 124894-1000 4
R408 1K, 0603, .1W, 5% 199403-102 4
R409 680 Milli- OHMS, 1210, 500mW, 5%, 318356-681J 4
R410 6.8 OHM, 1206, 1/4W, 5% 124895-6R85 4
R411 330 OHMS, 0603, .1W, 5%, 199403-331 4
R412 22.1K, 0603, .1W, 1% 191465-2212 4
R413 42.2 K, 0603, .1W, 1% 191465-4222 4
R414 510 OHM, 0603, .1W, 1%, 510 191465-5100 4
R415 825 OHM, 0603, SMD, 100MW, 1% 191465-8250 4
R416 1K, 0603, .1W, 5% 199403-102 4
R417 130K , 0402, 63MW, 1% 268361-1303 4
R419 1.27K, 0603, 1/10W, 1% 191465-1271 4
R420 3.9K, 0603, .1W, 1% 191465-3901 4
R421 121 OHM, 0603, .1W, 1%, 191465-1210 4
R422 210 OHM, 0603, .1W, 1%, 191465-2100 4
R423 JUMPER, CHIP, 0603 196042 4
R424 JUMPER, CHIP, 0603 196042 4
R425 JUMPER, CHIP, 0603 196042 4
R426 22 OHMS, 0603, .1W, 5% 199403-220 4
R427 10K, 0603, .1W, 1% 191465-1002 4
R428 2.2 OHM, 1206, 1/4W, 5% 124895-2R25 4
R429 6.8 OHM, 1206, 1/4W, 5% 124895-6R85 4
Reference
Designator
Description Part Number Note
R430 10K, 0603, .1W, 1% 191465-1002 4
R431 3.9K, 0603, .1W, 1% 191465-3901 4
R432 1.00K, 0805, 1/10W, 5% 133626-1025 4
R600 10K, 0603, .1W, 5% 199403-103 4
R601 10K, 0603, .1W, 5% 199403-103 4
R602 330 OHM, 0603, .1W, 1%, 191465-3300 4
R603 330 OHM, 0603, .1W, 1% 191465-3300 4
R604 2K, 0603, .1W, 1% 191465-2001 4
R605 10K, 0603, .1W, 5% 199403-103 4
R606 100K, 0603, .1W, 5% 199403-104 4
R607 49.9K, 0603, .1W, 1% 191465-4992 4
R608 475 OHM, 0603, .1W, 1%, 191465-4750 4
R609 100 OHM, 0603, .1W, 5% 199403-101 4
R611 51 OHM, 0805, 1/10W, 5% 133626-5105 4
R612 51 OHM, 0805, 1/10W, 5% 133626-5105 4
R613 51 OHM, 0805, 1/10W, 5% 133626-5105 4
R614 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R615 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R616 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R617 100 OHM, 1206, 1/4W, 1% 124894-1000 4
R800 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R801 1K, 0603, .1W, 5% 199403-102 4
R802 10K, 0603, .1W, 5% 199403-103 4
R803 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R804 100 OHM, 0603, .1W, 5% 199403-101 4
R805 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R806 10K, 0603, .1W, 5% 199403-103 4
R807 10K, 0603, .1W, 5% 199403-103 4
R808 10K, 0603, .1W, 1% 191465-1002 4
R809 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R810 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R811 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R812 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R813 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R814 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R815 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R816 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R817 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R818 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R819 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R820 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R821 51 OHM, 0805, 1/10W, 5% 133626-5105 4
R822 51 OHM , 0805, 1/10W, 5% 133626-5105 4
R823 51 OHM, 0805, 1/10W, 5% 133626-5105 4
R824 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R825 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R826 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R827 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R828 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R829 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R830 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R831 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R832 4.7K, 0603, .1W, 5%, 199403-472 4
R833 10K, 0603, .1W, 1% 191465-1002 4
R834 10K, 0603, .1W, 1% 191465-1002 4
R835 330 OHM, 0603, .1W, 1% 191465-3300 4
R836 10K, ARRAY, SMT, 4 POS, 5% 186433-1034 4
R837 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R838 10K, 0603, .1W, 1% 191465-1002 4
R839 10K, 0603, .1W, 1% 191465-1002 4
R840 10K, 0603, .1W, 5% 199403-103 4
R841 10K , ARRAY, SMT, 4 POS, 50V, 5% 186433-1034 4
R842 0603, .1W, 1%, 100K 191465-1003 4
R846 10K, ARRAY, SMT, 4 POS, 5% 186433-1034 4
R850 10K, 0603, .1W, 5% 199403-103 4
R851 10K, 0603, .1W, 5% 199403-103 4
R854 JUMPER, CHIP, 0603 196042 4
R855 JUMPER, CHIP, 0603 196042 4
R856 JUMPER, CHIP, 0603 196042 4
R857 JUMPER, CHIP, 0603 196042 4
R859 330 OHM, 0805, 1/10W, 5% 133626-3315 4
R900 10K, 0603, .1W, 5% 199403-103 4
R901 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R902 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R903 4.7K, 0603, .1W, 5%, 199403-472 4
