Bose SoundDock 10 Service Manual

10
ELECTRICAL PART LIST
DSP PCB Assembly
Resistors (continued)
Reference
Designator
Description Part Number Note
R904 1K, 0603, .1W, 5% 199403-102 4
R905 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R906 4.7K, 0603, .1W, 5% 199403-472 4
R907 10K, 0603, .1W, 1% 191465-1002 4
R908 10K , ARRAY, SMT, 4 POS, 50V, 5% 186433-1034 4
R909 100 OHM, 0603, .1W, 1%, 191465-1000 4
R910 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R911 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R912 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R913 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R914 47 OHM, 0603, SMD, 100MW, 5% 199403-470 4
R915 1K, 0603, .1W, 5% 199403-102 4
R916 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R917 10K, 0603, .1W, 1% 191465-1002 4
R918 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R919 49.9 OHM, 0402, 63MW, 1% 268361-49R9 4
R920 10K, 0603, .1W, 1% 191465-1002 4
R921 10K, 0603, .1W, 1% 191465-1002 4
R922 3.01K, 0603, .1W, 1% 191465-3011 4
R923 10K, 0603, .1W, 1% 191465-1002 4
R929 90.9K, 0603, .1W, 1% 191465-9092 4
R930 10K, 0603, .1W, 1% 191465-1002 4
R931 1K, 0603, .1W, 5% 199403-102 4
R932 10K, 0603, .1W, 1% 191465-1002 4
R933 51 OHM , 0805, 1/10W, 5% 133626-5105 4
Reference
Designator
Description Part Number Note
C301 1000, COG, 0603, 50V, 5% 188454-102 4
C302 1000, COG, 0603, 50V, 5% 188454-102 4
C303 1000, COG, 0603, 50V, 5% 188454-102 4
C304 1uF, TANT, 3216, 20V, 10% 268370-105 4
C305 1uF, TANT, 3216, 20V, 10% 268370-105 4
C306 1uF, TANT, 3216, 20V, 10% 268370-105 4
C307 1uF, TANT, 3216, 20V, 10% 268370-105 4
C308 0.1, X7R, 0603, 50V, 10% 191470-104 4
C309 1000, COG, 0603, 50V, 5% 188454-102 4
C310 33uF, EL, 85, 10V, 20% 177902-330A 4
C311 1000, COG, 0603, 50V, 5% 188454-102 4
C312 1000, COG, 0603, 50V, 5% 188454-102 4
C313 1uF, TANT, 3216, 20V, 10% 268370-105 4
C314 1uF, TANT, 3216, 20V, 10% 268370-105 4
C315 2.2uF, X7R, 1206, OPN, 16V, 10% 283163-225 4
C316 1000, COG, 0603, 50V, 5% 188454-102 4
C317 1, TANT, 3216, 20V, 10% 268370-105 4
C318 1, TANT, 3216, 20V, 10% 268370-105 4
C319 33nF, X7R, 0402, 16V, 5% 296732-333 4
C320 33nF, X7R, 0402, 16V, 5% 296732-333 4
C321 22pF, COG, 0402, 50V, 5% 268364-220 4
C322 22pF, COG, 0402, 50V, 5% 268364-220 4
C323 22pF, COG, 0402, 50V, 5% 268364-220 4
C324 22pF, COG, 0402, 50V, 5% 268364-220 4
C325 22pF, COG, 0402, 50V, 5% 268364-220 4
C326 22pF, COG, 0402, 50V, 5% 268364-220 4
C327 22pF, COG, 0402, 50V, 5% 268364-220 4
C328 22pF, COG, 0402, 50V, 5% 268364-220 4
C329 22pF, COG, 0402, 50V, 5% 268364-220 4
C400 470, COG, 0603, 50V, 5% 188454-471 4
C401 1000, COG, 0603, 50V, 5% 188454-102 4
C402 47, X7R, 0603, 50V, 10% 191470-470 4
C403 2200pF, 0603, X7R, 50V, 10% 191470-222 4
C404 0.1, X7R, 0603, 50V, 10% 191470-104 4
C405 0.1, X7R, 0603, 50V, 10% 191470-104 4
C406 1.0, X7R, 1206, 50V, 10% 286500-105 4
C407 100, COG, 0603, 50V, 5% 188454-101 4
C408 220, COG, 0603, 50V, 5% 188454-221 4
C409 4.7uF, CER, 1210, X7R, 25V, 10% 291431-475 4
C410 2.2, X5R, 1206, 25V, 20% 310601-2253M 4
C411 2.2, X5R, 1206, 25V, 20% 310601-2253M 4
C412 2200pF, 0603, X7R, 50V, 10% 191470-222 4
C413 47, CER, 1206, X5R, 6.3V, 20% 291432-476 4
C414 47, CER, 1206, X5R, 6.3V, 20% 291432-476 4
C415 .022, X7R , 0603, 50V, 10% 191470-223 4
C416 22uF, CER, 1206, X5R, 16V, 20% 321689-226 4
C417 4.7, TANT, 1411, 20V, 20% 188588-475 4
C418 4.7, TANT, 1411, 20V, 20% 188588-475 4
C419 1.0, X7R, 1206, 50V, 10% 286500-105 4
C420 4.7, TANT, 1411, 20V, 20% 188588-475 4
C421 4.7uF, 1411, TANT, 20V, 20% 188588-475 4
C427 2200pF, 0603, X7R, 50V, 10% 191470-222 4
C429 0.1uF, X7R, 0603, 50V, 10% 191470-104 4
C430 39.2K, 0603, 1/10W, 0.1% 282986-3922 4
C431 0.1, X7R, 0603, 50V, 10% 191470-104 4
C432 470pF, 0603, COG, 50V, 5% 188454-471 4
C433 0.1, X7R, 0603, 50V, 10% 191470-104 4
C600 33pF, 0603, COG, 50V, 5% 188454-330 4
C601 33pF, 0603, COG, 50V, 5% 188454-330 4
C602 33pF, 0603, COG, 50V, 5% 188454-330 4
C603 1000pF, C0G, 25V, 5% 268364-102 4
C604 33nF, X7R, 0402, 16V, 5% 296732-333 4
C605 0.1, X7R, 0603, 50V, 10% 191470-104 4
C606 33nF, X7R, 0402, 16V, 5% 296732-333 4
C607 33pF, 0603, COG, 50V, 5% 188454-330 4
C608 33pF, 0603, COG, 50V, 5% 188454-330 4
C609 33pF, 0603, COG, 50V, 5% 188454-330 4
C610 15, COG, 0603, 50V, 5% 188454-150 4
C611 1000pF, C0G, 25V, 5% 268364-102 4
C612 15, COG, 0603, 50V, 5% 188454-150 4
C613 33nF, X7R, 0402, 16V, 5% 296732-333 4
C614 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C615 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C616 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C617 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C618 68pF, COG, 0402, 50V, 5% 268364-680 4
Capacitors (continued).
Capacitors
Reference
Designator
Description Part Number Note
C201 18, COG, 0603, 50V, 5% 188454-181 4
C200 180pF, 0603, COG, 50V, 5% 188454-181 4
C202 18, COG, 0603, 50V, 5% 188454-181 4
C203 180pF, 0603, COG, 50V, 5% 188454-181 4
C204 3.3uF, TANT, 3216, 16V, 10% 268370-335 4
C205 3.3uF, TANT, 3216, 16V, 10% 268370-335 4
C206 3.3uF, TANT, 3216, 16V, 10% 268370-335 4
C207 3.3uF, TANT, 3216, 16V, 10% 268370-335 4
C208 18, COG, 0603, 50V, 5% 188454-181 4
C209 180pF, 0603, COG, 50V, 5% 188454-181 4
C210 18, COG, 0603, 50V, 5% 188454-181 4
C211 18, COG, 0603, 50V, 5% 188454-181 4
C212 0.1, X7R, 0603, 50V, 10% 191470-104 4
C213 0.1, X7R, 0603, 50V, 10% 191470-104 4
C214 18, COG, 0603, 50V, 5% 188454-181 4
C215 18, COG, 0603, 50V, 5% 188454-181 4
C216 .01, X7R , 0603, 50V, 10% 191470-103 4
C217 .01, X7R , 0603, 50V, 10% 191470-103 4
C218 18, COG, 0603, 50V, 5% 188454-181 4
C219 18, COG, 0603, 50V, 5% 188454-181 4
C220 18, COG, 0603, 50V, 5% 188454-181 4
C221 18, COG, 0603, 50V, 5% 188454-181 4
C222 2.2uF, X7R, 1206, OPN, 16V, 10% 283163-225 4
C223 1000pF, 0603, COG, 50V, 5% 188454-102 4
C224 18, COG, 0603, 50V, 5% 188454-181 4
C225 1000pF, 0603, COG, 50V, 5% 188454-102 4
C226 1000, COG, 0603, 50V, 5% 188454-102 4
C227 10uF ,TANT, A SIZE, 10V, 20% 196981-
A106A2
4
C228 10uF ,TANT, A SIZE, 10V, 20% 196981-
A106A2
4
C229 0.1, X7R, 0603, 50V, 10% 191470-104 4
C230 0.1, X7R, 0603, 50V, 10% 191470-104 4
C231 10uF ,TANT, A SIZE, 10V, 20% 196981-
A106A2
4
C232 1000, COG, 0603, 50V, 5% 188454-102 4
C233 33pF, 0603, COG, 50V, 5% 188454-330 4
C234 33nF, X7R, 0402, 16V, 5% 296732-333 4
C235 33nF, X7R, 0402, 16V, 5% 296732-333 4
C236 22pF, COG, 0402, 50V, 5% 268364-220 4
C237 22pF, COG, 0402, 50V, 5% 268364-220 4
C238 22pF, COG, 0402, 50V, 5% 268364-220 4
C239 22pF, COG, 0402, 50V, 5% 268364-220 4
C240 22pF, COG, 0402, 50V, 5% 268364-220 4
C300 1000, COG, 0603, 50V, 5% 188454-102 4

Bose SoundDock 10 Specifications

General

Frequency range	- Hz
RMS rated power	- W
Audio output channels	- channels
Bluetooth	Yes
Composite video out	1
Headphone connectivity	-
FM radio	No
Apple docking compatibility	iPhone, iPod
Dimensions (WxDxH)	432 x 244 x 221 mm
Cables included	AC
Product color	Silver

Weight and Dimensions

Weight	8400 g
