Bose SoundDock 10 Service Manual

11
ELECTRICAL PART LIST
DSP PCB Assembly
Capacitors (continued)
Reference
Designator
Description Part Number Note
C830 68pF, COG, 0402, 50V, 5% 268364-680 4
C831 68pF, 0603, COG, 50V, 5% 188454-680 4
C832 68pF, COG, 0402, 50V, 5% 268364-680 4
C833 1500pF, 0603, X7R, 50V, 10% 191470-152 4
C834 100pF, COG, 0402, 50V, 5% 268364-101 4
C835 68pF, COG, 0402, 50V, 5% 268364-680 4
C836 68pF, COG, 0402, 50V, 5% 268364-680 4
C837 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C838 68pF, COG, 0402, 50V, 5% 268364-680 4
C839 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C840 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C841 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C842 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C843 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C844 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C845 68pF, COG, 0402, 50V, 5% 268364-680 4
C846 68pF, COG, 0402, 50V, 5% 268364-680 4
C847 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C848 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C849 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C850 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C851 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C852 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C853 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C854 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C855 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C856 27pF, COG, 0402, 50V, 5% 268364-270 4
C857 27pF, COG, 0402, 50V, 5% 268364-270 4
C858 27pF, COG, 0402, 50V, 5% 268364-270 4
C859 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C860 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C861 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C862 68pF, COG, 0402, 50V, 5% 268364-680 4
C863 68pF, COG, 0402, 50V, 5% 268364-680 4
C864 68pF, COG, 0402, 50V, 5% 268364-680 4
C865 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C866 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C867 68pF, COG, 0402, 50V, 5% 268364-680 4
C868 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C869 68pF, COG, 0402, 50V, 5% 268364-680 4
C870 68pF, COG, 0402, 50V, 5% 268364-680 4
C871 68pF, COG, 0402, 50V, 5% 268364-680 4
C872 68pF, COG, 0402, 50V, 5% 268364-680 4
C873 68pF, COG, 0402, 50V, 5% 268364-680 4
C874 68pF, COG, 0402, 50V, 5% 268364-680 4
C875 68pF, COG, 0402, 50V, 5% 268364-680 4
C876 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C877 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C878 68pF, COG, 0402, 50V, 5% 268364-680 4
C879 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C880 68pF, COG, 0402, 50V, 5% 268364-680 4
C881 68pF, COG, 0402, 50V, 5% 268364-680 4
C882 68pF, COG, 0402, 50V, 5% 268364-680 4
C883 68pF, COG, 0402, 50V, 5% 268364-680 4
C884 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C885 68pF, COG, 0402, 50V, 5% 268364-680 4
C886 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C887 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C888 0.1, X7R, 0603, 50V, 10% 191470-104 4
C900 10, TANT, A SIZE, 6.3V, 20% 196981-
J106A2
4
C901 33nF, X7R, 0402, 16V, 5% 296732-333 4
C902 0.1uF, X7R, 0603, 50V, 10% 191470-104 4
C903 33nF, X7R, 0402, 16V, 5% 296732-333 4
C904 33nF, X7R, 0402, 16V, 5% 296732-333 4
C905 1000, COG, 0603, 50V, 5% 188454-102 4
C906 27, COG, 0603, 50V, 5% 188454-270 4
C907 27, COG, 0603, 50V, 5% 188454-270 4
C908 10uF, TANT, A SIZE, 6.3V, 20% 196981-
J106A2
4
C909 0.1, X7R, 0603, 50V, 10% 191470-104 4
C911 0.1, X7R, 0603, 50V, 10% 191470-104 4
C912 0.1, X7R, 0603, 50V, 10% 191470-104 4
C913 0.1uF, X7R, 0603, 50V, 10% 191470-104 4
C916 0.1, X7R, 0603, 50V, 10% 191470-104 4
Capacitors (continued)
Reference
Designator
Description Part Number Note
C619 68pF, COG, 0402, 50V, 0.1%, 268364-680 4
C700 100uF, 7343, TANT, lo-R, 10V, 10% 275411-107 4
C701 33nF, X7R, 0402, 16V, 5% 296732-333 4
C702 1000pF, C0G, 25V, 5% 268364-102 4
C703 33nF, X7R, 0402, 16V, 5% 296732-333 4
C704 1000pF, C0G, 25V, 5% 268364-102 4
C705 33nF, X7R, 0402, 16V, 5% 296732-333 4
C706 1000pF, C0G, 25V, 5% 268364-102 4
C707 33nF, X7R, 0402, 16V, 5% 296732-333 4
C708 33nF, X7R, 0402, 16V, 5% 296732-333 4
C709 1000pF, C0G, 25V, 5% 268364-102 4
C710 33nF, X7R, 0402, 16V, 5% 296732-333 4
C711 1000pF, C0G, 25V, 5% 268364-102 4
C712 33nF, X7R, 0402, 16V, 5% 296732-333 4
C713 1000pF, C0G, 25V, 5% 268364-102 4
C714 33nF, X7R, 0402, 16V, 5% 296732-333 4
C715 10, TANT, A SIZE, 6.3V, 20%
196981-
J106A2
4
C716 68pF, COG, 0402, 50V, 5% 268364-680 4
C717 68pF, COG, 0402, 50V, 5% 268364-680 4
C719 68pF, 0603, COG, 50V, 5% 188454-680 4
C720 68pF, COG, 0402, 50V, 5% 268364-680 4
C721 68pF, COG, 0402, 50V, 5% 268364-680 4
C722 68pF, COG, 0402, 50V, 5% 268364-680 4
C723 68pF, COG, 0402, 50V, 5% 268364-680 4
C724 68pF, COG, 0402, 50V, 5% 268364-680 4
C725 68pF, COG, 0402, 50V, 5% 268364-680 4
C726 68pF, COG, 0402, 50V, 5% 268364-680 4
C727 68pF, COG, 0402, 50V, 5% 268364-680 4
C728 68pF, COG, 0402, 50V, 5% 268364-680 4
C729 68pF, COG, 0402, 50V, 5% 268364-680 4
C730 68pF, COG, 0402, 50V, 5% 268364-680 4
C731 68pF, 0603, COG, 50V, 5% 188454-680 4
C732 68pF, COG, 0402, 50V, 5% 268364-680 4
C733 68pF, COG, 0402, 50V, 5% 268364-680 4
C734 68pF, COG, 0402, 50V, 5% 268364-680 4
C735 68pF, COG, 0402, 50V, 5% 268364-680 4
C736 68pF, COG, 0402, 50V, 5% 268364-680 4
C737 68pF, COG, 0402, 50V, 5% 268364-680 4
C738 68pF, COG, 0402, 50V, 5% 268364-680 4
C739 68pF, COG, 0402, 50V, 5% 268364-680 4
C740 68pF, COG, 0402, 50V, 5% 268364-680 4
C741 68pF, COG, 0402, 50V, 5% 268364-680 4
C742 68pF, COG, 0402, 50V, 5% 268364-680 4
C743 68pF, COG, 0402, 50V, 5% 268364-680 4
C744 68pF, COG, 0402, 50V, 5% 268364-680 4
C800 33nF, X7R, 0402, 16V, 5% 296732-333 4
C801 1000pF, C0G, 25V, 5% 268364-102 4
C802 33nF, X7R, 0402, 16V, 5% 296732-333 4
C803 1000pF, C0G, 25V, 5% 268364-102 4
C804 33nF, X7R, 0402, 16V, 5% 296732-333 4
C805 1000pF, C0G, 25V, 5% 268364-102 4
C806 33nF, X7R, 0402, 16V, 5% 296732-333 4
C807 1000pF, C0G, 25V, 5% 268364-102 4
C808 33nF, X7R, 0402, 16V, 5% 296732-333 4
C809 1000pF, C0G, 25V, 5% 268364-102 4
C810 33nF, X7R, 0402, 16V, 5% 296732-333 4
C811 1000pF, C0G, 25V, 5% 268364-102 4
C812 10, TANT, A SIZE, 6.3V, 20%
196981-
J106A2
4
C816 33nF, X7R, 0402, 16V, 5% 296732-333 4
C817 22pF, 0603, COG, 50V, 5% 188454-220 4
C817 22pF, 0603, COG, 50V, 5% 188454-220 4
C818 33pF, 0603, COG, 50V, 5% 188454-330 4
C819 33pF, 0603, COG, 50V, 5% 188454-330 4
C820 33pF, 0603, COG, 50V, 5% 188454-330 4
C821 68pF, COG, 0402, 50V, 5% 268364-680 4
C822 68pF, COG, 0402, 50V, 5% 268364-680 4
C823 68pF, COG, 0402, 50V, 5% 268364-680 4
C824 68pF, COG, 0402, 50V, 5% 268364-680 4
C825 68pF, 0603, COG, 50V, 5% 188454-680 4
C826 68pF, COG, 0402, 50V, 5% 268364-680 4
C827 68pF, COG, 0402, 50V, 5% 268364-680 4
C828 68pF, COG, 0402, 50V, 5% 268364-680 4
C829 68pF, COG, 0402, 50V, 5% 268364-680 4
